Hazardous Loc Mtr, 3-Ph, EPFC, 3/4 HP, T3B MPN:056T17G5316
Hazardous Loc Mtr, 3-Ph, EPFC, 3/4 HP, T3B
This 3-phase hazardous location motor from Leeson is designed for use in environments where electrical safety is paramount, such as in the oil and gas industry. With a 3/4 horsepower rating and 1,725 RPM, it provides reliable power for a variety of applications, including pumps, fans, and conveyor systems. The motor's totally enclosed fan-cooled design ensures efficient cooling and reduced maintenance needs. Its Class I and Class II hazardous location rating makes it suitable for use in areas with flammable gases or dust. Ideal for use in environments with high temperatures and harsh conditions.
Top product features:
- Three-phase design for efficient operation
- Totally enclosed fan cooled for reliable heat dissipation
- Continuous duty cycle for uninterrupted performance
Top product applications:
- Food Processing Equipment
- Petrochemical Plants
- Oil Refineries
Hazardous Location Motor, Three Phase, Motor Design Three-Phase, 3/4 hp HP, Nameplate RPM 1,725 RPM, No. of Speeds 1, Voltage 208-230/460V AC, Full Load Amps 2.9-3.0/1.5 A, 56C Frame, Usable @ 208V Usable at 208V, Usable @ 200V Not Usable at 200V, Hz 60 Hz, Max. Ambient Temp. 40 Degrees C, Motor Service Factor 1, Motor Thermal Protection Auto, Ins. Class B, Hazardous Location Class Class I, Class II, Temp. Code T3B, Motor Enclosure Design Totally Enclosed Fan Cooled, Duty Cycle Continuous
Additional Information
- Country of Origin: US
- Drop Ship Item: No
- Blind Ship Eligible: No
- LTL Freight Required: No
- Lead Time: Ships in 1 days
- Minimum Order Quantity: 1
- Unit of Measure: EA
- Package Length: 16.38
- Package Width: 10.50
- Package Height: 8.12
- Package Weight: 29.00
Product info last updated on February 26, 2026 5:53pm UTC
Category: Motors
