Capacitor-Start General Purpose Motor, 1 hp HP, 115/208-230V AC Voltage, 56 Frame MPN:056C34F5310
Capacitor-Start General Purpose Motor, 1 hp HP, 115/208-230V AC Voltage, 56 Frame
This 1 hp, single-phase capacitor-start general purpose motor from Leeson is designed for a wide range of applications. Suitable for use at 115/208-230V AC, it provides reliable operation and efficient energy use in various settings. The motor's totally enclosed fan-cooled design ensures long-lasting performance and durability, while its continuous duty cycle capability makes it ideal for applications with high usage demands. With a service factor of 1.15, this motor is perfect for use in commercial and industrial settings, including manufacturing facilities, warehouses, and more, where reliable and efficient power is essential.
Top product features:
- Totally Enclosed Fan Cooled design provides a safe and reliable operating environment.
- Motor is designed for single-phase operation.
- Capacitor-start motor design provides efficient power conversion for continuous duty operation.
Top product applications:
- Pumps
- Fans
- Compressors
General Purpose Motor, Single Phase, Motor Design Capacitor-Start, 1 hp HP, Nameplate RPM 3,450 RPM, No. of Speeds 1, Voltage 115/208-230V AC, Full Load Amps 12.4/6.7-6.2 A, 56 Frame, Usable @ 208V Usable at 208V, Usable @ 200V Not Usable at 200V, Hz 60 Hz, Motor Service Factor 1.15, Max. Ambient Temp. 40 Degrees C, Motor Thermal Protection None, Duty Cycle Continuous, Ins. Class B, Motor Enclosure Design Totally Enclosed Fan Cooled, Motor Shaft Rotation CW/CCW, Motor Mounting Type Rigid Base
Additional Information
- Country of Origin: ZZ
- Drop Ship Item: No
- Blind Ship Eligible: No
- LTL Freight Required: No
- Lead Time: Ships in 1 days
- Minimum Order Quantity: 1
- Unit of Measure: EA
- Package Length: 16.12
- Package Width: 10.25
- Package Height: 9.12
- Package Weight: 30.00
