Close-Coupled Pump Motor, 3-Ph, 1-1/2 HP MPN:145TTDR6034
Close-Coupled Pump Motor, 3-Ph, 1-1/2 HP
This Leeson Close-Coupled Pump Motor is a reliable and efficient solution for various applications requiring continuous duty cycles. Suitable for use in pump systems, it features a 3-phase design, 1.5 HP output, and a durable ball-bearing construction. With a high inverter rating of 10:1 variable torque and 2:1 constant torque, it can handle demanding tasks with ease. The motor's compact size, measuring 6.5 inches in diameter and 10.875 inches in length, makes it ideal for installations with limited space. Its continuous duty cycle and high-temperature tolerance make it suitable for use in industrial settings, including water treatment and chemical processing plants.
Top product features:
- Continuous duty cycle for continuous operation
- Inverter rated for 10:1 variable torque and 2:1 constant torque
- Ball bearings for reduced motor wear and increased reliability
Top product applications:
- Pump
- Motor Application
- Inverter Rated
Close-Coupled Pump Motor, Body Dia. 6.5 in, Bolt Circle Dia. 5 7/8 in, CC Number CC003A, Conduit Box Location Exterior, Conduit Box Position F1, Duty Cycle Continuous, Frame 145JM, Hz 60 Hz, Full Load Amps 4.4/2.2, Height 6 11/16 in, HP 1 1/2, Ins. Class F, Inverter Rated Inverter Rated, Inverter Rating 10:1 Variable Torque, 2:1 Constant Torque, Length Less Shaft 10 7/8 in, Max. Ambient Temp. 40 Degrees C, Motor Application Pump, Motor Bearings Ball, Motor Design Three-Phase
Additional Information
- Country of Origin: US
- Drop Ship Item: No
- Blind Ship Eligible: No
- LTL Freight Required: No
- Lead Time: Ships in 1 days
- Minimum Order Quantity: 1
- Unit of Measure: EA
- Package Length: 19.31
- Package Width: 11.19
- Package Height: 9.75
- Package Weight: 46.00
Product info last updated on February 15, 2026 10:30pm UTC
Category: Motors
