Motor, 3/4 HP, 1725 RPM, 115/208-230V MPN:056C17F5308
Motor, 3/4 HP, 1725 RPM, 115/208-230V
This 3/4 HP single phase motor from Leeson is a reliable and efficient solution for a variety of applications. Designed for continuous duty, it features a capacitor-start design and a totally enclosed fan cooled enclosure for optimal performance and protection. With a nameplate RPM of 1725 and a voltage range of 115-230V, it can be used in a range of settings, including commercial and industrial environments. The motor's compact size and lightweight design make it easy to install and maintain, and its 1.15 service factor ensures it can handle demanding tasks with ease.
Top product features:
- Totally Enclosed Fan Cooled design for improved durability and reliability
- Manual thermal protection to prevent overheating and extend motor life
- Continuous duty cycle capability for sustained operation without overheating
Top product applications:
- Pump applications
- Conveyor systems
- Machine tools
General Purpose Motor, Single Phase, Motor Design Capacitor-Start, 3/4 hp HP, Nameplate RPM 1,725 RPM, No. of Speeds 1, Voltage 115/208-230V AC, Full Load Amps 11.0/5.5-5.4 A, 56 Frame, Usable @ 208V Usable at 208V, Usable @ 200V Not Usable at 200V, Hz 60 Hz, Motor Service Factor 1.15, Max. Ambient Temp. 40 Degrees C, Motor Thermal Protection Manual, Duty Cycle Continuous, Ins. Class B, Motor Enclosure Design Totally Enclosed Fan Cooled, Motor Shaft Rotation CW/CCW
Additional Information
- Country of Origin: ZZ
- Drop Ship Item: No
- Blind Ship Eligible: No
- LTL Freight Required: No
- Lead Time: Ships in 1 days
- Minimum Order Quantity: 1
- Unit of Measure: EA
- Package Length: 16.12
- Package Width: 10.25
- Package Height: 9.12
- Package Weight: 29.00
