3-Phase Belt Drive Motor, 1 1/2, 3/8 HP, 145T Frame, 460V AC Voltage, 1, 740/855 Nameplate RPM MPN:145TTDR5702
3-Phase Belt Drive Motor, 1 1/2, 3/8 HP, 145T Frame, 460V AC Voltage, 1, 740/855 Nameplate RPM
This 3-Phase Belt Drive Motor from Leeson is a reliable and efficient solution for various applications. With a 1 1/2 HP rating and 145T frame, it can handle demanding tasks such as powering fans and blowers in industrial settings. The motor's 2-speed design allows for flexibility in operation, and its continuous duty cycle ensures uninterrupted performance. Suitable for use in environments with temperatures up to 40°C, this motor is ideal for applications in manufacturing, HVAC, and other industries where high airflow is required. Its rugged construction and open drip-proof design make it a durable and long-lasting choice.
Top product features:
- Three-Phase Belt Drive Motor
- Operates at two different speeds
- Has a rigid base mounting type
Top product applications:
- HVAC Systems
- Pumps and Compressors
- Fans and Blowers
Fan and Blower Motor, Three Phase, Motor Design Three-Phase, 1 1/2 hp, 3/8 hp HP, Nameplate RPM 1,740/855 RPM, No. of Speeds 2, Voltage 460V AC, 2.2/1.1 A Full Load Amps, 145T Frame, 60 Hz Hz, Usable @ 208V Not Usable at 208V, Usable @ 200V Not Usable at 200V, Motor Service Factor 1.15, Motor Thermal Protection None, Ins. Class B, Duty Cycle Continuous, Max. Ambient Temp. 40 Degrees C, Motor Shaft Rotation CW/CCW, Motor Enclosure Design Open Drip Proof, Motor Mounting Type Rigid Base
Additional Information
- Country of Origin: US
- Drop Ship Item: No
- Blind Ship Eligible: No
- LTL Freight Required: No
- Lead Time: Ships in 1 days
- Minimum Order Quantity: 1
- Unit of Measure: EA
- Package Length: 16.38
- Package Width: 10.50
- Package Height: 8.12
- Package Weight: 47.00
Product info last updated on March 18, 2026 4:44pm UTC
Category: Motors
