Capacitor-Start General Purpose Motor, 1 hp HP, 115/208-230V AC Voltage, 56 Frame MPN:5KC49PN0155
Capacitor-Start General Purpose Motor, 1 hp HP, 115/208-230V AC Voltage, 56 Frame
The Leeson Capacitor-Start General Purpose Motor is a reliable and efficient solution for a wide range of applications. Suitable for continuous duty, this 1 hp motor operates at 1,725 RPM and is designed for single-phase use. With a 56 frame size and voltage options of 115/208-230V AC, it can be used in various settings, including industrial and commercial environments. The motor's open drip-proof enclosure and CW/CCW rotation make it easy to integrate into existing systems. Its compact size and lightweight design also make it ideal for space-constrained areas, offering a cost-effective solution for motor needs.
Top product features:
- Single Phase Motor Design
- Capacitor-Start Motor Design
- Usable at 208V
Top product applications:
- Pumps and other fluid-handling equipment
- Fans and blowers for general ventilation and air circulation
- Conveyors and other machinery for material handling
General Purpose Motor, Single Phase, Motor Design Capacitor-Start, 1 hp HP, Nameplate RPM 1,725 RPM, No. of Speeds 1, Voltage 115/208-230V AC, Full Load Amps 13.6/6.8-6.7 A, 56 Frame, Usable @ 208V Usable at 208V, Usable @ 200V Not Usable at 200V, Hz 60 Hz, Motor Service Factor 1.15, Max. Ambient Temp. 40 Degrees C, Motor Thermal Protection None, Duty Cycle Continuous, Ins. Class B, Motor Enclosure Design Open Drip Proof, Motor Shaft Rotation CW/CCW, Motor Mounting Type Cradle Base
Additional Information
- Country of Origin: ZZ
- Drop Ship Item: No
- Blind Ship Eligible: No
- LTL Freight Required: No
- Lead Time: Ships in 1 days
- Minimum Order Quantity: 1
- Unit of Measure: EA
- Package Length: 13.69
- Package Width: 7.13
- Package Height: 7.50
- Package Weight: 31.00
Product info last updated on February 8, 2026 1:45am UTC
Category: Motors
