Vector Motor, 3-Phase, 1HP, 230/460V MPN:143THTN8028
Vector Motor, 3-Phase, 1HP, 230/460V
This 1HP 3-phase vector motor from Leeson is designed for high-efficiency applications that require precise speed control. With a nameplate RPM of 1,756 and a speed range of 2,000:1, it's ideal for use in processes that demand precise speed and torque control. Its continuous duty cycle and NEMA Design B rating make it suitable for applications such as conveyor systems, pumps, and fans. The motor's compact design and high power density also make it a great choice for space-constrained industrial settings, where reliability and efficiency are paramount.
Top product features:
- Three-phase design for efficient power distribution
- 1,756 nameplate RPM for high-speed applications
- 143TC frame design for compact and space-saving installation
Top product applications:
- Industrial Automation Systems
- Pumps and Pumping Systems
- Conveyor Systems
Vector Motor, Three Phase, Motor Design Three-Phase, 1 HP, Nameplate RPM 1,756, No. of Speeds 1, Voltage 230/460V AC, Full Load Amps 3.0/1.5 A, 143TC Frame, Max. Speed 5,400 RPM, Speed Range 2,000:1, Usable @ 208V Not Usable at 208V, Usable @ 200V Not Usable at 200V, 60 Hz Hz, Max. Operating Frequency 120 Hz, Motor Service Factor 1, Motor Thermal Protection T-Stat, Ins. Class H, Max. Ambient Temp. 104 Degrees F, Duty Cycle Continuous, NEMA Design B, Motor Shaft Rotation CW/CCW
Additional Information
- Country of Origin: ZZ
- Drop Ship Item: Yes
- Blind Ship Eligible: No
- LTL Freight Required: No
- Lead Time: Ships in 15 days
- Minimum Order Quantity: 1
- Unit of Measure: EA
- Package Length: 15.82
- Package Width: 12.56
- Package Height: 9.38
- Package Weight: 61.00
Product info last updated on March 11, 2026 4:23am UTC
Category: Motors
