Capacitor-Start General Purpose Motor, 1 hp HP, 115/208-230V AC Voltage, 56C Frame MPN:056C34F5324
Capacitor-Start General Purpose Motor, 1 hp HP, 115/208-230V AC Voltage, 56C Frame
The Leeson Capacitor-Start General Purpose Motor is a reliable and efficient solution for a wide range of applications. This single-phase motor is designed for continuous duty and is suitable for use in environments up to 40°C. With a 1 hp rating and 3,450 RPM, it's perfect for applications such as pumps, fans, and conveyors. The motor's capacitor-start design provides smooth starting and efficient operation, while its totally enclosed fan-cooled design ensures long life and minimal maintenance. Its compact size and lightweight design make it easy to install and integrate into existing systems.
Top product features:
- Totally Enclosed Fan Cooled design for improved motor protection and reduced maintenance
- Continuous duty cycle operation for uninterrupted performance
- Single Phase motor design with Capacitor-Start for efficient energy use
Top product applications:
- Pump
- Conveyor
- Fan
General Purpose Motor, Single Phase, Motor Design Capacitor-Start, 1 hp HP, Nameplate RPM 3,450 RPM, No. of Speeds 1, Voltage 115/208-230V AC, Full Load Amps 12.4/6.7-6.2 A, 56C Frame, Usable @ 208V Usable at 208V, Usable @ 200V Not Usable at 200V, Hz 60 Hz, Motor Service Factor 1.15, Max. Ambient Temp. 40 Degrees C, Motor Thermal Protection None, Duty Cycle Continuous, Ins. Class B, Motor Enclosure Design Totally Enclosed Fan Cooled, Motor Shaft Rotation CW/CCW, Motor Mounting Type C-Face
Additional Information
- Country of Origin: ZZ
- Drop Ship Item: No
- Blind Ship Eligible: No
- LTL Freight Required: No
- Lead Time: Ships in 1 days
- Minimum Order Quantity: 1
- Unit of Measure: EA
- Package Length: 16.12
- Package Width: 10.25
- Package Height: 9.12
- Package Weight: 29.00
