Condenser Fan Motor, 1 1/2 hp MPN:056T11O5306
Condenser Fan Motor, 1 1/2 hp
This Leeson Condenser Fan Motor is a reliable and efficient solution for various applications, including commercial and industrial cooling systems. With a 1 1/2 hp rating and 1,140 RPM, it provides consistent airflow and performance. Suitable for use in three-phase systems, it operates at 208-230/460V AC, making it adaptable to different voltage requirements. The motor's continuous duty cycle and auto thermal protection ensure long-lasting performance in demanding environments. Its compact design and open air over enclosure make it easy to install and maintain, making it an ideal choice for applications where space is limited.
Top product features:
- Three-Phase Design
- Has a Continuous Duty Cycle
- Operates at 1,140 RPM
Top product applications:
- Air Conditioning Units
- Industrial Refrigeration Systems
- Commercial HVAC Systems
Condenser Fan Motor, Three Phase, Motor Design Three-Phase, 1 1/2 hp HP, Nameplate RPM 1,140 RPM, No. of Speeds 1, Voltage 208-230/460V AC, 5.4-5.4/2.7 A Full Load Amps, 56HZ Frame, Output Watts 1100 W, 60/50 Hz Hz, Usable @ 208V Usable at 208V, Usable @ 200V Not Usable at 200V, Motor Service Factor 1, Motor Thermal Protection Auto, Ins. Class H, Duty Cycle Continuous, Max. Ambient Temp. 70 Degrees C, Motor Shaft Rotation CW/CCW, Motor Enclosure Design Open Air Over
Additional Information
- Country of Origin: ZZ
- Drop Ship Item: No
- Blind Ship Eligible: No
- LTL Freight Required: No
- Lead Time: Ships in 1 days
- Minimum Order Quantity: 1
- Unit of Measure: EA
- Package Length: 16.56
- Package Width: 7.50
- Package Height: 7.50
- Package Weight: 38.00
Product info last updated on April 6, 2026 9:06am UTC
Category: Motors
