Capacitor-Start General Purpose Motor, 3/4 hp HP, 115/208-230V AC Voltage, 56 Frame MPN:056C17D2074
Capacitor-Start General Purpose Motor, 3/4 hp HP, 115/208-230V AC Voltage, 56 Frame
This 3/4 hp Capacitor-Start General Purpose Motor from Leeson is designed for a wide range of applications, including industrial and commercial use. Its single-phase, capacitor-start motor design provides efficient and reliable performance. Suitable for use at 115/208-230V AC voltage, this motor is ideal for applications where a high starting torque is required. Its continuous duty cycle and open drip-proof enclosure make it suitable for use in harsh environments. With a motor service factor of 1.25 and a maximum ambient temperature of 40 degrees C, this motor is a reliable choice for applications such as conveyor systems, pumps, and fans.
Top product features:
- Operates at 1,725 RPM
- Has a capacitor-start design
- Is rated for continuous duty cycle
Top product applications:
- Pumps and water circulation systems
- Fans and ventilation systems
- Power tools and machinery
General Purpose Motor, Single Phase, Motor Design Capacitor-Start, 3/4 hp HP, Nameplate RPM 1,725 RPM, No. of Speeds 1, Voltage 115/208-230V AC, Full Load Amps 10.0/5.2-5.0 A, 56 Frame, Usable @ 208V Usable at 208V, Usable @ 200V Not Usable at 200V, Hz 60 Hz, Motor Service Factor 1.25, Max. Ambient Temp. 40 Degrees C, Motor Thermal Protection Auto, Duty Cycle Continuous, Ins. Class B, Motor Enclosure Design Open Drip Proof, Motor Shaft Rotation CW/CCW, Motor Mounting Type Cradle Base
Additional Information
- Country of Origin: MX
- Drop Ship Item: No
- Blind Ship Eligible: No
- LTL Freight Required: No
- Lead Time: Ships in 1 days
- Minimum Order Quantity: 1
- Unit of Measure: EA
- Package Length: 12.44
- Package Width: 8.06
- Package Height: 8.75
- Package Weight: 23.00
