Three-Phase General Purpose Motor, 1 HP, 143T Frame, 230/460V AC Voltage, 1735 rpm Nameplate RPM MPN:143TTFN16040
Three-Phase General Purpose Motor, 1 HP, 143T Frame, 230/460V AC Voltage, 1735 rpm Nameplate RPM
This Leeson Three-Phase General Purpose Motor is a reliable and efficient solution for a wide range of industrial applications. Suitable for continuous duty, it operates at 1735 rpm and provides 1 horsepower of power. The motor is designed for use in environments with a maximum ambient temperature of 40 degrees C, and features a totally enclosed fan cooled motor enclosure for optimal performance. Its high efficiency of 85.5% reduces energy consumption and minimizes environmental impact. Ideal for use in manufacturing, material handling, and other industrial settings, this motor offers a durable and cost-effective solution for demanding applications.
Top product features:
- Three-Phase AC Voltage Capability
- Totally Enclosed Fan Cooled Motor Enclosure Design
- Ball Motor Bearings
Top product applications:
- Pump Motor
- Industrial Fan Motor
- Compressor Motor
General Purpose Motor, Three-Phase, Totally Enclosed Fan Cooled Motor Enclosure Design, 1 HP, Nameplate RPM 1735 rpm, Frame 143T, Voltage 230/460V AC, 60 Hz Hz, Three Phase, Full Load Amps 3.0/1.5 A, Rigid Base Motor Mounting Type, Motor Thermal Protection None, Ins. Class F, Motor Service Factor 1.15, Ball Motor Bearings, Motor Frame Material Cast Iron, Max. Ambient Temp. 40 Degrees C, CW/CCW Motor Shaft Rotation, Nominal Efficiency 85.5 Percent, Continuous Duty, 1701-1800
Additional Information
- Country of Origin: ZZ
- Drop Ship Item: No
- Blind Ship Eligible: No
- LTL Freight Required: No
- Lead Time: Ships in 1 days
- Minimum Order Quantity: 1
- Unit of Measure: EA
- Package Length: 22.50
- Package Width: 16.81
- Package Height: 14.75
- Package Weight: 65.00
Product info last updated on February 7, 2026 8:57pm UTC
Category: Motors
