General Purpose Farm Duty Motor, Capacitor-Start/Run, 1 HP, 115/208-230V AC, 1, 725 Nameplate RPM MPN:5KCR49SN0493S
General Purpose Farm Duty Motor, Capacitor-Start/Run, 1 HP, 115/208-230V AC, 1, 725 Nameplate RPM
This General Purpose Farm Duty Motor from Leeson is a reliable and efficient solution for various agricultural applications. With a single-phase, capacitor-start/run design, it provides a continuous duty cycle and can operate at 115/208-230V AC. The motor's 1 HP rating and 1,725 nameplate RPM make it suitable for tasks such as irrigation systems, pumps, and other farm equipment. Its totally enclosed non-ventilated design ensures protection from dust and moisture, while the cradle base mounting type provides easy installation and maintenance. The motor's 1.3 service factor and auto thermal protection ensure reliable operation in harsh farm environments.
Top product features:
- Capacitor-start/run design for improved starting torque and efficiency
- Totally enclosed non-ventilated motor enclosure for dust and moisture protection
- Continuous duty cycle for reliable operation in demanding applications
Top product applications:
- Pump for irrigation systems
- Aerator for small ponds or lakes
- Well pump for residential use
Farm Duty Motor, Single Phase, Motor Design Capacitor-Start/Run, 1 hp HP, Nameplate RPM 1,725 RPM, No. of Speeds 1, Voltage 115/208-230V AC, Full Load Amps 10.6/5.5-5.3 A, 56 Frame, Usable @ 208V Usable at 208V, Usable @ 200V Not Usable at 200V, 60 Hz Hz, Motor Service Factor 1.3, Motor Thermal Protection Auto, Ins. Class B, Max. Ambient Temp. 40 Degrees C, Duty Cycle Continuous, Motor Shaft Rotation CW/CCW, Motor Enclosure Design Totally Enclosed Non-Ventilated, Motor Mounting Type Cradle Base
Additional Information
- Country of Origin: MX
- Drop Ship Item: No
- Blind Ship Eligible: No
- LTL Freight Required: No
- Lead Time: Ships in 1 days
- Minimum Order Quantity: 1
- Unit of Measure: EA
- Package Length: 13.69
- Package Width: 7.13
- Package Height: 7.50
- Package Weight: 34.00
Product info last updated on February 25, 2026 5:01am UTC
Category: Motors
