General Purpose Farm Duty Motor, Split-Phase, 1/3 HP, 115V AC, 1, 725 Nameplate RPM, 48Z Frame MPN:5KH33JNA500S
General Purpose Farm Duty Motor, Split-Phase, 1/3 HP, 115V AC, 1, 725 Nameplate RPM, 48Z Frame
The Leeson General Purpose Farm Duty Motor is a reliable and efficient solution for agricultural applications. Suitable for continuous use, this 1/3 HP, 115V AC motor operates at 1,725 Nameplate RPM and features a 48Z frame for added durability. Its auto thermal protection and Class B insulation ensure safe and reliable operation in harsh farm environments. With its cradle base mounting and totally enclosed non-ventilated design, this motor is ideal for applications such as irrigation pumps, grain dryers, and other farm equipment. Its compact size and lightweight design make it easy to install and maintain, reducing downtime and increasing productivity.
Top product features:
- Split-phase motor design for efficient operation
- Totally enclosed non-ventilated enclosure for protection from dust and moisture
- Continuous duty cycle for reliable operation in demanding applications
Top product applications:
- Pump or irrigation system for a small farm or ranch
- General purpose machinery such as a grain auger or conveyor
- Small-scale agricultural equipment like a planter or cultivator
Farm Duty Motor, Single Phase, Motor Design Split-Phase, 1/3 hp HP, Nameplate RPM 1,725 RPM, No. of Speeds 1, Voltage 115V AC, Full Load Amps 6.2 A, 48Z Frame, Usable @ 208V Not Usable at 208V, Usable @ 200V Not Usable at 200V, 60 Hz Hz, Motor Service Factor 1.35, Motor Thermal Protection Auto, Ins. Class B, Max. Ambient Temp. 40 Degrees C, Duty Cycle Continuous, Motor Shaft Rotation CW/CCW, Motor Enclosure Design Totally Enclosed Non-Ventilated, Motor Mounting Type Cradle Base
Additional Information
- Country of Origin: MX
- Drop Ship Item: No
- Blind Ship Eligible: No
- LTL Freight Required: No
- Lead Time: Ships in 1 days
- Minimum Order Quantity: 1
- Unit of Measure: EA
- Package Length: 12.63
- Package Width: 6.94
- Package Height: 7.50
- Package Weight: 15.00
Product info last updated on February 6, 2026 1:50am UTC
Category: Motors
