General Purpose Farm Duty Motor, Split-Phase, 1/2 HP, 115/208-230V AC, 1, 725 Nameplate RPM, 56 Frame MPN:5KH42JN0328S
General Purpose Farm Duty Motor, Split-Phase, 1/2 HP, 115/208-230V AC, 1, 725 Nameplate RPM, 56 Frame
This Leeson General Purpose Farm Duty Motor is a reliable and efficient solution for various agricultural applications. With a 1/2 HP rating and 1,725 nameplate RPM, it can handle demanding tasks such as irrigation, pumping, and equipment operation. The motor's split-phase design and totally enclosed air-over enclosure ensure durability and protection from harsh environments. Its continuous duty cycle and auto thermal protection make it suitable for long-running applications. Ideal for use in farm settings, this motor provides a cost-effective and dependable solution for farmers and agricultural professionals. Its compact size and easy mounting make it a convenient choice for various applications.
Top product features:
- Totally Enclosed Air-Over Motor Enclosure Design
- Motor Shaft Rotation in Both Clockwise and Counterclockwise Directions
- Continuous Duty Cycle Operation
Top product applications:
- Pump applications for irrigation and water supply systems
- General purpose machinery and equipment such as generators and compressors
- Fans and blowers for agricultural and industrial ventilation systems
Farm Duty Motor, Single Phase, Motor Design Split-Phase, 1/2 hp HP, Nameplate RPM 1,725 RPM, No. of Speeds 1, Voltage 115/208-230V AC, Full Load Amps 8.0/4.0-4.0 A, 56 Frame, Usable @ 208V Usable at 208V, Usable @ 200V Not Usable at 200V, 60 Hz Hz, Motor Service Factor 1, Motor Thermal Protection Auto, Ins. Class B, Max. Ambient Temp. 40 Degrees C, Duty Cycle Continuous, Motor Shaft Rotation CW/CCW, Motor Enclosure Design Totally Enclosed Air-Over, Motor Mounting Type Cradle Base
Additional Information
- Country of Origin: MX
- Drop Ship Item: No
- Blind Ship Eligible: No
- LTL Freight Required: No
- Lead Time: Ships in 1 days
- Minimum Order Quantity: 1
- Unit of Measure: EA
- Package Length: 13.69
- Package Width: 7.13
- Package Height: 7.50
- Package Weight: 21.00
Product info last updated on February 12, 2026 3:10pm UTC
Category: Motors
