Oil Burner Motor, 1/8 hp MPN:048S17T286
Oil Burner Motor, 1/8 hp
This 1/8 hp Oil Burner Motor from Leeson is a reliable and efficient solution for various applications. Suitable for use in oil burner systems, it provides a continuous duty cycle in a totally enclosed non-ventilated design. With a 115V AC single-phase motor, it operates at 1,725 nameplate RPM and 2.6 amps of full load current. The motor's compact 48N frame and steel construction make it ideal for a range of installations, from residential to commercial settings. Its continuous operation and manual thermal protection ensure a consistent performance, making it a valuable addition to any oil burner system.
Top product features:
- Totally Enclosed Nonventilated motor enclosure provides protection from dust and debris
- Single Phase motor design allows for simple and efficient operation
- Continuous duty cycle enables long-term operation without overheating
Top product applications:
- Oil Burner
- HVAC Fan
- Water Pump
HVAC Motor, Single Phase, Motor Design Split-Phase, 1/8 HP, Nameplate RPM 1,725, No. of Speeds 1, Voltage 115V AC, 2.6 A Full Load Amps, 48N Frame, Output Watts 90 W, 60 Hz Hz, Usable @ 208V No, Usable @ 200V No, Motor Service Factor 1, Motor Thermal Protection Manual, Ins. Class B, Duty Cycle Continuous, Max. Ambient Temp. 40 Degrees C, Motor Shaft Rotation CW/CCW, Motor Enclosure Design Totally Enclosed Nonventilated, Motor Mounting Type Face, Motor Frame Material Steel
Additional Information
- Country of Origin: MX
- Drop Ship Item: No
- Blind Ship Eligible: No
- LTL Freight Required: No
- Lead Time: Ships in 1 days
- Minimum Order Quantity: 1
- Unit of Measure: EA
- Package Length: 11.06
- Package Width: 6.75
- Package Height: 6.62
- Package Weight: 11.00
Product info last updated on February 5, 2026 8:46pm UTC
Category: Motors
