Oil Burner Motor, 1/2 hp MPN:048C34D2028
Oil Burner Motor, 1/2 hp
This 1/2 hp Leeson oil burner motor is a reliable and efficient solution for various applications, including oil burner systems, HVAC, and industrial processes. Its single-phase, capacitor-start design provides a high level of performance and durability. With a nameplate RPM of 3,450 and a continuous duty cycle, this motor is suitable for demanding applications. Its compact 48NZ frame and open drip-proof enclosure make it easy to install and maintain. Suitable for use at 115/208-230V AC, this motor is a versatile and cost-effective option for a wide range of industries and applications.
Top product features:
- Capacitor-start design for efficient motor operation
- Single-phase motor suitable for various applications
- Continuous duty cycle for uninterrupted operation
Top product applications:
- Oil burner motor for residential heating systems
- HVAC motor for air conditioning and ventilation systems
- Industrial machinery motor for applications requiring a 1/2 horsepower motor
HVAC Motor, Single Phase, Motor Design Capacitor-Start, 1/2 HP, Nameplate RPM 3,450, No. of Speeds 1, Voltage 115/208-230V AC, 7.4/3.5-3.7 A Full Load Amps, 48NZ Frame, Output Watts 370 W, 60 Hz Hz, Usable @ 208V Yes, Usable @ 200V No, Motor Service Factor 1, Motor Thermal Protection Manual, Ins. Class B, Duty Cycle Continuous, Max. Ambient Temp. 40 Degrees C, Motor Shaft Rotation CW/CCW, Motor Enclosure Design Open Dripproof, Motor Mounting Type Face, Motor Frame Material Steel
Additional Information
- Country of Origin: MX
- Drop Ship Item: No
- Blind Ship Eligible: No
- LTL Freight Required: No
- Lead Time: Ships in 1 days
- Minimum Order Quantity: 1
- Unit of Measure: EA
- Package Length: 12.44
- Package Width: 9.13
- Package Height: 8.06
- Package Weight: 17.00
Product info last updated on February 3, 2026 5:26pm UTC
Category: Motors
