Oil Burner Motor, 1/4 hp MPN:048S17S25
Oil Burner Motor, 1/4 hp
This 1/4 hp oil burner motor from Leeson is a reliable and efficient solution for various applications. Suitable for use in single-phase systems, it operates at 1,725 RPM and provides 190 watts of output. Its compact 48N frame design makes it easy to mount and integrate into existing systems. The motor is ideal for use in oil-fired furnaces, boilers, and other heating equipment. Its continuous duty cycle and manual thermal protection ensure reliable operation in a wide range of environments. With a lead time of just one day, this motor is perfect for applications where timely installation is crucial.
Top product features:
- Split-phase motor design for efficient operation
- Continuous duty cycle for uninterrupted performance
- Manual thermal protection for safe operation
Top product applications:
- Oil burner motor for residential heating systems
- Oil burner motor for industrial heating equipment
- Oil burner motor for commercial heating systems
HVAC Motor, Single Phase, Motor Design Split-Phase, 1/4 HP, Nameplate RPM 1,725, No. of Speeds 1, Voltage 115V AC, 3.9 A Full Load Amps, 48N Frame, Output Watts 190 W, 60 Hz Hz, Usable @ 208V No, Usable @ 200V No, Motor Service Factor 1, Motor Thermal Protection Manual, Ins. Class B, Duty Cycle Continuous, Max. Ambient Temp. 40 Degrees C, Motor Shaft Rotation CW/CCW, Motor Enclosure Design Open Air-Over, Motor Mounting Type Face, Motor Frame Material Steel
Additional Information
- Country of Origin: MX
- Drop Ship Item: No
- Blind Ship Eligible: No
- LTL Freight Required: No
- Lead Time: Ships in 1 days
- Minimum Order Quantity: 1
- Unit of Measure: EA
- Package Length: 12.44
- Package Width: 9.13
- Package Height: 8.06
- Package Weight: 12.00
Product info last updated on February 1, 2026 11:52pm UTC
Category: Motors
