Washdown Motor, 3/4HP, 3-Phase Design, 60Hz MPN:113022.00
Discount: See in Cart
Free Shipping
In Stock
Free Shipping
In Stock
SKU
510-G4608941
Washdown Motor, 3/4HP, 3-Phase Design, 60Hz
This 3/4 HP, 3-phase washdown motor from Leeson is designed for use in harsh environments where high levels of cleanliness are required. With a totally enclosed, non-ventilated design and a high IP rating, it can withstand exposure to water and chemicals. Its continuous duty cycle and NEMA Design B rating make it suitable for heavy-duty applications such as food processing, pharmaceutical manufacturing, and other industries where reliability and cleanliness are paramount. The motor's compact size and removable base make it easy to install and maintain, providing a cost-effective solution for a wide range of washdown applications.
Top product features:
- Three-phase design
- Totally enclosed non-ventilated motor enclosure
- Continuous duty cycle
Top product applications:
- Pump applications in food processing and chemical plants
- Chemical processing equipment in pharmaceutical manufacturing
- Water treatment plants and wastewater treatment facilities
Washdown Motor, Three Phase, Motor Design Three-Phase, 3/4 hp HP, Nameplate RPM 3,450 RPM, No. of Speeds 1, Voltage 230/460V AC, Full Load Amps 2.4/1.2 A, 56C Frame, Usable @ 208V Usable at 208V, Usable @ 200V Not Usable at 200V, 60 Hz Hz, Motor Service Factor 1.15, Motor Thermal Protection None, Ins. Class F, Max. Ambient Temp. 40 Degrees C, Duty Cycle Continuous, NEMA Design B, Removable Base No, Motor Shaft Rotation CW/CCW, Motor Enclosure Design Totally Enclosed Non-Ventilated
Additional Information
- Country of Origin: US
- Drop Ship Item: No
- Blind Ship Eligible: No
- LTL Freight Required: No
- Lead Time: Ships in 1 days
- Minimum Order Quantity: 1
- Unit of Measure: EA
- Package Length: 14.90
- Package Width: 11.00
- Package Height: 11.90
- Package Weight: 31.70
