Washdown Motor, 3-Phase, 1 HP, 208-230/460V AC, 1, 750 Nameplate RPM, 56HC Frame MPN:119785.00
Discount: See in Cart
Free Shipping
In Stock
Free Shipping
In Stock
SKU
510-G4608296
Washdown Motor, 3-Phase, 1 HP, 208-230/460V AC, 1, 750 Nameplate RPM, 56HC Frame
This 1 HP, 3-phase washdown motor from Leeson is designed for heavy-duty applications in harsh environments. With a nameplate RPM of 1,750 and a 56HC frame, it provides reliable operation in demanding conditions. Suitable for use at 208V, this motor is ideal for applications such as food processing, chemical handling, and other industries where washdown is required. Its totally enclosed non-ventilated design and rigid base mounting ensure maximum protection and durability. With a lead time of 15 days, this motor can be easily integrated into your operations, providing a cost-effective solution for your washdown needs.
Top product features:
- Totally Enclosed Non-Ventilated motor enclosure design provides protection against dust and moisture
- Usable at 208V AC operating voltage allows for flexibility in installation
- Continuous duty cycle enables the motor to operate without interruption for extended periods
Top product applications:
- Pump and irrigation systems in agricultural settings
- Conveyor systems in manufacturing facilities
- Centrifuges and separators in food processing and waste management
Farm Duty Motor, Three Phase, Motor Design Three-Phase, 1 hp HP, Nameplate RPM 1,750 RPM, No. of Speeds 1, Voltage 208-230/460V AC, Full Load Amps 3.0-2.8/1.4 A, 56HC Frame, Usable @ 208V Usable at 208V, Usable @ 200V Not Usable at 200V, 60/50 Hz Hz, Motor Service Factor 1.15, Motor Thermal Protection None, Ins. Class F, Max. Ambient Temp. 40 Degrees C, Duty Cycle Continuous, Motor Shaft Rotation CW/CCW, Motor Enclosure Design Totally Enclosed Non-Ventilated
Additional Information
- Country of Origin: MX
- Drop Ship Item: Yes
- Blind Ship Eligible: No
- LTL Freight Required: No
- Lead Time: Ships in 15 days
- Minimum Order Quantity: 1
- Unit of Measure: EA
- Package Length: 23.50
- Package Width: 17.00
- Package Height: 19.40
- Package Weight: 168.00
Product info last updated on February 28, 2026 7:14am UTC
Category: Motors
