WashdownMotor, 5hp, 3495RPMJM, 230/460VAC MPN:132443.00
Discount: See in Cart
Free Shipping
In Stock
Free Shipping
In Stock
SKU
510-G406626658
WashdownMotor, 5hp, 3495RPMJM, 230/460VAC
This rugged 5hp washdown motor from Marathon is designed for use in harsh environments where high-pressure washes and chemical cleaning are common. Its totally enclosed fan-cooled design and Class F insulation ensure reliable operation in temperatures up to 40°C. With a continuous duty cycle and NEMA Design B rating, it's ideal for applications in food processing, pharmaceutical, and other industries where cleanliness and sanitation are critical. Its compact 184JM frame and three-phase design make it easy to integrate into existing systems, providing a reliable and efficient solution for demanding washdown applications.
Top product features:
- Three-phase motor design
- Totally enclosed fan cooled motor enclosure
- Continuous duty cycle capability
Top product applications:
- Food Processing
- Pumping Stations
- Pharmaceutical Manufacturing
Washdown Motor, Three Phase, Motor Design Three-Phase, 5 hp HP, Nameplate RPM 3,495 RPM, No. of Speeds 1, Voltage 230/460V AC, Full Load Amps 13.2-12.0/6.0 A, 184JM Frame, Usable @ 208V Usable at 208V, Usable @ 200V Usable at 200V, 60/50 Hz Hz, Motor Service Factor 1.15, Motor Thermal Protection None, Ins. Class F, Max. Ambient Temp. 40 Degrees C, Duty Cycle Continuous, NEMA Design B, Motor Shaft Rotation CW/CCW, Motor Enclosure Design Totally Enclosed Fan Cooled
Additional Information
- Country of Origin: MX
- Drop Ship Item: No
- Blind Ship Eligible: No
- LTL Freight Required: No
- Lead Time: Ships in 1 days
- Minimum Order Quantity: 1
- Unit of Measure: EA
- Package Length: 18.20
- Package Width: 13.50
- Package Height: 13.80
- Package Weight: 88.00
Product info last updated on February 13, 2026 6:46pm UTC
Category: Motors
