Vector Motor, 4.5 lb-ft, 1 HP, 230/460 V MPN:145THTR5326
Vector Motor, 4.5 lb-ft, 1 HP, 230/460 V
The Leeson Vector Motor is a high-performance, 1.5 HP, three-phase motor designed for demanding applications. With a 4.5 lb-ft torque and 5,400 RPM max speed, it provides a wide speed range of 1,000:1. Suitable for use in a variety of industries, including manufacturing, material handling, and oil and gas, this motor is ideal for applications requiring high efficiency and reliability. Its compact design and CW/CCW rotation make it a versatile choice for a range of tasks, from pumping and conveying to compressing and conveying. Its robust construction and continuous duty cycle ensure reliable operation in harsh environments.
Top product features:
- Three-phase motor design
- Continuous duty cycle operation
- 145TC frame design
Top product applications:
- Air Compressor
- Pump
- Conveyor System
Vector Motor, Three Phase, Motor Design 3-Phase, 1 1/2 HP, Nameplate RPM 1,755, No. of Speeds 1, Voltage 230/460V AC, Full Load Amps 4.8/2.4 A, 145TC Frame, Torque 4.5 ft-lb, Max. Speed 5,400 RPM, Speed Range 1,000:1, Usable @ 208V No, Usable @ 200V No, 60 Hz Hz, Max. Operating Frequency 120 Hz, Motor Service Factor 1, Motor Thermal Protection None, Ins. Class F, Max. Ambient Temp. 104 Degrees F, Duty Cycle Continuous, NEMA Design A, Motor Shaft Rotation CW/CCW
Additional Information
- Country of Origin: ZZ
- Drop Ship Item: No
- Blind Ship Eligible: No
- LTL Freight Required: No
- Lead Time: Ships in 1 days
- Minimum Order Quantity: 1
- Unit of Measure: EA
- Package Length: 19.88
- Package Width: 10.25
- Package Height: 8.12
- Package Weight: 50.00
Product info last updated on January 19, 2026 10:37pm UTC
Category: Motors
