Instant Rev Motor, 1/4 HP, 1725 RPM, 115 V MPN:5KC35GNA488
Instant Rev Motor, 1/4 HP, 1725 RPM, 115 V
The Leeson Instant Rev Motor is a reliable and efficient solution for a variety of applications, including conveyor systems, packaging machinery, and material handling equipment. With its 1/4 HP, 1725 RPM, and single-phase design, this motor provides smooth and quiet operation. Its capacitor-start design and 1.35 service factor make it suitable for continuous duty cycles, while its open drip-proof enclosure protects against dust and moisture. The motor's rigid base and all-angle mounting position offer flexibility in installation. Ideal for use in manufacturing, warehousing, and logistics settings, this motor is a cost-effective and durable choice for demanding applications.
Top product features:
- Instant Reverse Motor operation allows for bidirectional rotation
- Capacitor-start design provides a boost to motor starting torque
- Single-phase operation simplifies installation and setup
Top product applications:
- Air Compressor
- Pump
- Fan Motor
Instant Reverse Motor, Single Phase, Motor Design Capacitor-Start, 1/4 hp HP, Nameplate RPM 1,725 RPM, No. of Speeds 1, Voltage 115V AC, Full Load Amps 5.2 A, 48 Frame, 60 Hz Hz, Motor Service Factor 1.35, Motor Thermal Protection None, Ins. Class B, Max. Ambient Temp. 40 Degrees C, Duty Cycle Continuous, Motor Shaft Rotation CW/CCW, Motor Enclosure Design Open Drip Proof, Motor Mounting Type Rigid Base, Motor Mounting Position All Angle, Number of Wires 4, Motor Frame Material Steel
Additional Information
- Country of Origin: MX
- Drop Ship Item: No
- Blind Ship Eligible: No
- LTL Freight Required: No
- Lead Time: Ships in 1 days
- Minimum Order Quantity: 1
- Unit of Measure: EA
- Package Length: 12.63
- Package Width: 6.94
- Package Height: 7.50
- Package Weight: 14.00
Product info last updated on February 2, 2026 11:15pm UTC
Category: Motors
