Mtr, Cap St, 1.5 HP, 3450, 115/230V, 56C, TEFC MPN:5KC49SN2156X
Mtr, Cap St, 1.5 HP, 3450, 115/230V, 56C, TEFC
This Leeson 1.5 HP motor is designed for general-purpose use in a variety of applications, including pumps and other machinery. Its totally enclosed fan-cooled (TEFC) design provides protection from dust and moisture, while its capacitor-start design delivers efficient operation. The motor's ball bearings ensure smooth and quiet operation, and its steel frame provides durability and stability. With a continuous duty cycle and a maximum ambient temperature of 104°F, this motor is suitable for use in a range of environments. Its standard efficient design and compact size make it an ideal choice for a variety of industrial and commercial applications.
Top product features:
- Totally Enclosed Fan Cooled design for improved cooling and reduced noise
- Ball bearings for smooth and quiet operation
- Capacitor-Start design for efficient starting and reduced energy consumption
Top product applications:
- Pumps
- Motor Bearings Ball
- Motor Application Pumps
General Purpose Motor, Single Phase, Motor Design Capacitor-Start, 1 1/2 HP, Nameplate RPM 3,450, No. of Speeds 1, Voltage 115/230V AC, Full Load Amps 16.4, 8.2 A, 56C Frame, Usable @ 208V Not Usable at 208V, Usable @ 200V Not Usable at 200V, Hz 60 Hz, Motor Service Factor 1, Max. Ambient Temp. 104 Degrees F, Motor Thermal Protection Auto, Duty Cycle Continuous, Ins. Class B, Motor Enclosure Design Totally Enclosed Fan Cooled, Motor Shaft Rotation CW/CCW, Motor Mounting Type C-Face
Additional Information
- Country of Origin: MX
- Drop Ship Item: No
- Blind Ship Eligible: No
- LTL Freight Required: No
- Lead Time: Ships in 1 days
- Minimum Order Quantity: 1
- Unit of Measure: EA
- Package Length: 15.14
- Package Width: 10.19
- Package Height: 9.50
- Package Weight: 35.00
Product info last updated on February 26, 2026 10:22pm UTC
Category: Motors
