Capacitor-Start/Run General Purpose Motor, 1/3 hp HP, 115/230V AC Voltage, 56C Frame MPN:056B17D11014
Capacitor-Start/Run General Purpose Motor, 1/3 hp HP, 115/230V AC Voltage, 56C Frame
This 1/3 hp motor from Leeson is a reliable and efficient choice for a wide range of applications, including industrial and commercial settings. Its capacitor-start/run design provides a smooth and consistent operation, making it ideal for use in applications such as pumps, fans, and conveyor systems. The motor's open drip-proof enclosure and continuous duty cycle make it suitable for harsh environments and heavy usage. With a service factor of 1.35 and a maximum ambient temperature of 40 degrees C, this motor can handle demanding tasks with ease, providing a reliable and long-lasting solution for your business needs.
Top product features:
- Capacitor-start/run design for improved efficiency and reliability
- Single-phase motor for use in a variety of applications
- Continuous duty cycle for high usage scenarios
Top product applications:
- Pumps and water treatment systems
- Fans and blowers for ventilation and air conditioning
- Machine tools and machinery for various industrial applications
General Purpose Motor, Single Phase, Motor Design Capacitor-Start/Run, 1/3 hp HP, Nameplate RPM 1,725 RPM, No. of Speeds 1, Voltage 115/230V AC, Full Load Amps 3.8/1.9 A, 56C Frame, Usable @ 208V Not Usable at 208V, Usable @ 200V Not Usable at 200V, Hz 60 Hz, Motor Service Factor 1.35, Max. Ambient Temp. 40 Degrees C, Motor Thermal Protection None, Duty Cycle Continuous, Ins. Class B, Motor Enclosure Design Open Drip Proof, Motor Shaft Rotation CW/CCW, Motor Mounting Type C-Face, Rigid Base
Additional Information
- Country of Origin: MX
- Drop Ship Item: No
- Blind Ship Eligible: No
- LTL Freight Required: No
- Lead Time: Ships in 1 days
- Minimum Order Quantity: 1
- Unit of Measure: EA
- Package Length: 11.75
- Package Width: 5.75
- Package Height: 7.25
- Package Weight: 19.00
Product info last updated on February 1, 2026 10:53am UTC
Category: Motors
