Mtr, Cap St, 1/3 HP, 3450, 115/230V, 56J MPN:5KC37FN65X
Mtr, Cap St, 1/3 HP, 3450, 115/230V, 56J
This Leeson 1/3 HP general-purpose pump motor is designed for continuous duty cycles, making it ideal for a wide range of applications including pool pumps, water circulation systems, and irrigation systems. Its capacitor-start design and ball bearings ensure efficient operation and long motor life. The motor's open drip-proof enclosure and steel frame provide durability and protection from the elements. With a compact size and standard efficient design, this motor is a reliable choice for any pump-based system. Its 115/230V operation and 3.0-3.2A full load amps make it easy to integrate into existing systems.
Top product features:
- Continuous Duty Cycle
- Ball Bearings
- Capacitor-Start Motor Design
Top product applications:
- General Purpose Pump
- Motor Application Pump
- Pump
Jet Pump Motor, Body Dia. 5.6 in, Bolt Circle Dia. 2 15/16 in, Conduit Box Location Exterior, Duty Cycle Continuous, Frame 56J, Hz 60 Hz, Full Load Amps 6.4, 3.0-3.2, HP 1/3, Includes Shaft Slinger, Ins. Class B, Length Less Shaft 8 13/16 in, Max. Ambient Temp. 40 Degrees C, Motor Application Pump, Motor Bearings Ball, Motor Design Capacitor-Start, Motor Efficiency Group Standard Efficient, Motor Enclosure Design Open Dripproof, Motor Frame Material Steel
Additional Information
- Country of Origin: MX
- Drop Ship Item: No
- Blind Ship Eligible: No
- LTL Freight Required: No
- Lead Time: Ships in 1 days
- Minimum Order Quantity: 1
- Unit of Measure: EA
- Package Length: 13.69
- Package Width: 7.13
- Package Height: 7.50
- Package Weight: 14.00
Product info last updated on March 5, 2026 12:16pm UTC
Category: Motors
