Capacitor-Start/Run General Purpose Motor, 1/2 hp HP, 100-120/200-240V AC Voltage, 56C Frame MPN:5KCR46MN0055X
Capacitor-Start/Run General Purpose Motor, 1/2 hp HP, 100-120/200-240V AC Voltage, 56C Frame
This 1/2 hp Capacitor-Start/Run General Purpose Motor from Leeson is a reliable and efficient solution for various applications. Suitable for use in 100-120/200-240V AC environments, it features a 56C frame and a single-phase design with a nameplate RPM of 1,725. The motor is totally enclosed fan cooled and has a continuous duty cycle, making it ideal for industrial and commercial settings. With a motor service factor of 1.25 and auto thermal protection, it provides optimal performance and longevity. Its compact size and lightweight design make it easy to integrate into existing systems, making it a versatile and practical choice for a wide range of applications.
Top product features:
- Totally Enclosed Fan Cooled design for improved motor longevity and reduced maintenance
- Single Phase motor design for compatibility with a wide range of electrical systems
- Continuous duty cycle for uninterrupted operation and increased productivity
Top product applications:
- Industrial textile machinery
- Pumps and irrigation systems
- Conveyor systems
General Purpose Motor, Single Phase, Motor Design Capacitor-Start/Run, 1/2 hp HP, Nameplate RPM 1,725 RPM, No. of Speeds 1, Voltage 100-120/200-240V AC, Full Load Amps 5.6/2.8 A, 56C Frame, Usable @ 208V Not Usable at 208V, Usable @ 200V Usable at 200V, Hz 60/50 Hz, Motor Service Factor 1.25, Max. Ambient Temp. 40 Degrees C, Motor Thermal Protection Auto, Duty Cycle Continuous, Ins. Class B, Motor Enclosure Design Totally Enclosed Fan Cooled, Motor Shaft Rotation CW/CCW
Additional Information
- Country of Origin: MX
- Drop Ship Item: No
- Blind Ship Eligible: No
- LTL Freight Required: No
- Lead Time: Ships in 1 days
- Minimum Order Quantity: 1
- Unit of Measure: EA
- Package Length: 15.14
- Package Width: 10.19
- Package Height: 9.50
- Package Weight: 29.00
Product info last updated on January 19, 2026 11:32pm UTC
Category: Motors
