Capacitor-Start General Purpose Motor, 3/4 hp HP, 115/208-230V AC Voltage, 56C Frame MPN:056C17F5322
Capacitor-Start General Purpose Motor, 3/4 hp HP, 115/208-230V AC Voltage, 56C Frame
The Leeson Capacitor-Start General Purpose Motor is a reliable and efficient solution for a wide range of applications. Suitable for use in 115/208-230V AC environments, this motor offers a high power output of 3/4 hp and a robust 56C frame design. Ideal for continuous duty cycles, it can operate in temperatures up to 40°C and features a totally enclosed fan-cooled design for optimal performance and durability. Perfect for industries such as manufacturing, food processing, and HVAC, this motor provides a cost-effective and low-maintenance solution for applications requiring a single-phase motor with a high service factor.
Top product features:
- Totally Enclosed Fan Cooled design for improved motor durability and reduced maintenance
- Continuous duty cycle for uninterrupted operation in high-demand applications
- Single Phase motor design with Capacitor-Start for efficient and reliable power conversion
Top product applications:
- Industrial Laundry Machines
- Pumps and Water Pumps
- Fans and Blowers
General Purpose Motor, Single Phase, Motor Design Capacitor-Start, 3/4 hp HP, Nameplate RPM 1,725 RPM, No. of Speeds 1, Voltage 115/208-230V AC, Full Load Amps 11.0/5.5-5.4 A, 56C Frame, Usable @ 208V Usable at 208V, Usable @ 200V Not Usable at 200V, Hz 60/50 Hz, Motor Service Factor 1.15, Max. Ambient Temp. 40 Degrees C, Motor Thermal Protection None, Duty Cycle Continuous, Ins. Class B, Motor Enclosure Design Totally Enclosed Fan Cooled, Motor Shaft Rotation CW/CCW
Additional Information
- Country of Origin: MX
- Drop Ship Item: No
- Blind Ship Eligible: No
- LTL Freight Required: No
- Lead Time: Ships in 1 days
- Minimum Order Quantity: 1
- Unit of Measure: EA
- Package Length: 16.12
- Package Width: 10.25
- Package Height: 9.12
- Package Weight: 30.00
Product info last updated on February 4, 2026 6:01pm UTC
Category: Motors
