Condenser Fan Motor, 1/2 hp MPN:048A11O2017
Condenser Fan Motor, 1/2 hp
Boost your HVAC system's efficiency with the Leeson 1/2 hp Condenser Fan Motor, designed for single-phase applications. This motor's permanent split capacitor design and 1,075 RPM nameplate speed make it ideal for condenser fan applications. With a 1.4 A full-load current and 370 W output, it provides reliable performance and energy efficiency. Suitable for continuous duty cycles in ambient temperatures up to 40°C, this motor is perfect for use in commercial and industrial settings. Its compact 48Z frame and open-air design make it easy to install and maintain, ensuring optimal airflow and system performance.
Top product features:
- Permanent Split Capacitor motor design
- Single Phase operation
- Continuous duty cycle operation
Top product applications:
- Air Conditioning Units
- Heat Pumps
- Commercial Refrigeration Systems
Condenser Fan Motor, Single Phase, Motor Design Permanent Split Capacitor, 1/2 hp HP, Nameplate RPM 1,075 RPM, No. of Speeds 1, Voltage 460V AC, 1.4 A Full Load Amps, 48Z Frame, Output Watts 370 W, 60 Hz Hz, Usable @ 208V Not Usable at 208V, Usable @ 200V Not Usable at 200V, Motor Service Factor 1, Motor Thermal Protection Auto, Ins. Class B, Duty Cycle Continuous, Max. Ambient Temp. 40 Degrees C, Motor Shaft Rotation CW/CCW, Motor Enclosure Design Open Air Over, Motor Mounting Type Stud
Additional Information
- Country of Origin: MX
- Drop Ship Item: No
- Blind Ship Eligible: No
- LTL Freight Required: No
- Lead Time: Ships in 1 days
- Minimum Order Quantity: 1
- Unit of Measure: EA
- Package Length: 13.25
- Package Width: 7.00
- Package Height: 6.94
- Package Weight: 16.00
Product info last updated on January 31, 2026 9:04am UTC
Category: Motors
