Condenser Fan Motor, 3/4 hp MPN:048A11O2016
Condenser Fan Motor, 3/4 hp
This 3/4 hp condenser fan motor from Leeson is a reliable and efficient solution for a variety of applications. With a permanent split capacitor design and single-phase operation, it's ideal for use in commercial and industrial settings. The motor's 1,075 RPM and 560 W output make it suitable for condenser fan applications, while its continuous duty cycle and 40°C ambient temperature rating ensure reliable operation in demanding environments. Suitable for 460V AC, the motor is perfect for use in air conditioning, refrigeration, and HVAC systems, providing a cost-effective and long-lasting solution for your business.
Top product features:
- Permanent Split Capacitor motor design
- Output of 560 watts
- Continuous duty cycle
Top product applications:
- Air Conditioning Units
- HVAC Systems
- Industrial Cooling Systems
Condenser Fan Motor, Single Phase, Motor Design Permanent Split Capacitor, 3/4 hp HP, Nameplate RPM 1,075 RPM, No. of Speeds 1, Voltage 460V AC, 2.5 A Full Load Amps, 48Y Frame, Output Watts 560 W, 60 Hz Hz, Usable @ 208V Not Usable at 208V, Usable @ 200V Not Usable at 200V, Motor Service Factor 1, Motor Thermal Protection Auto, Ins. Class B, Duty Cycle Continuous, Max. Ambient Temp. 40 Degrees C, Motor Shaft Rotation CW/CCW, Motor Enclosure Design Open Air Over, Motor Mounting Type Stud
Additional Information
- Country of Origin: MX
- Drop Ship Item: No
- Blind Ship Eligible: No
- LTL Freight Required: No
- Lead Time: Ships in 1 days
- Minimum Order Quantity: 1
- Unit of Measure: EA
- Package Length: 13.25
- Package Width: 7.00
- Package Height: 6.94
- Package Weight: 19.00
Product info last updated on February 1, 2026 5:14am UTC
Category: Motors
