Condenser Fan Motor, 1/2 hp MPN:048A17O172
Condenser Fan Motor, 1/2 hp
Upgrade your HVAC system with the Leeson 1/2 hp Condenser Fan Motor, designed for single-phase applications. This high-performance motor operates at 1,625 RPM and 370 watts, providing efficient cooling in a range of environments. Its permanent split capacitor design and continuous duty cycle make it suitable for demanding applications. Use it in commercial or industrial settings, such as rooftop units, chillers, and air handlers. The motor's compact 48Y frame and open air over design ensure optimal airflow and heat dissipation. With a 1-day lead time and 1-unit minimum order quantity, this motor is ready to meet your needs.
Top product features:
- Permanent Split Capacitor motor design
- Single Phase operation
- Continuous duty cycle
Top product applications:
- HVAC systems
- Packaged rooftop units
- Air-cooled chillers
Condenser Fan Motor, Single Phase, Motor Design Permanent Split Capacitor, 1/2 hp HP, Nameplate RPM 1,625 RPM, No. of Speeds 1, Voltage 460V AC, 1.7 A Full Load Amps, 48Y Frame, Output Watts 370 W, 60 Hz Hz, Usable @ 208V Not Usable at 208V, Usable @ 200V Not Usable at 200V, Motor Service Factor 1, Motor Thermal Protection Auto, Ins. Class B, Duty Cycle Continuous, Max. Ambient Temp. 40 Degrees C, Motor Shaft Rotation CW/CCW, Motor Enclosure Design Open Air Over, Motor Mounting Type Stud
Additional Information
- Country of Origin: MX
- Drop Ship Item: No
- Blind Ship Eligible: No
- LTL Freight Required: No
- Lead Time: Ships in 1 days
- Minimum Order Quantity: 1
- Unit of Measure: EA
- Package Length: 13.25
- Package Width: 7.00
- Package Height: 6.94
- Package Weight: 15.00
Product info last updated on February 5, 2026 6:28pm UTC
Category: Motors
