Farm Duty Motor, Capacitor-Start/Run, 1 1/2 HP, 115/208-230V AC, 1, 740 Nameplate RPM, 145T Frame MPN:145TBFR5328
Discount: See in Cart
Free Shipping
In Stock
Free Shipping
In Stock
SKU
510-G200722808
Farm Duty Motor, Capacitor-Start/Run, 1 1/2 HP, 115/208-230V AC, 1, 740 Nameplate RPM, 145T Frame
The Leeson Farm Duty Motor is a reliable and efficient solution for demanding agricultural applications. With a 1.5 HP capacity and 1,740 RPM nameplate speed, this motor is designed to handle the rigors of farm work. Its capacitor-start/run design provides a high starting torque, making it ideal for applications such as irrigation pumps, grain dryers, and other heavy-duty equipment. The motor's totally enclosed fan-cooled design ensures reliable operation in harsh environments, while its 1.15 service factor and manual thermal protection provide added peace of mind. Perfect for continuous duty cycles, this motor is a valuable addition to any farm or agricultural operation.
Top product features:
- Capacitor-start/run design for improved starting torque and efficiency
- Totally enclosed fan cooled design for protection from dust and moisture
- Continuous duty cycle for uninterrupted operation
Top product applications:
- Pumps and well systems
- Grain dryers
- Sprinkler systems
Farm Duty Motor, Single Phase, Motor Design Capacitor-Start/Run, 1 1/2 hp HP, Nameplate RPM 1,740 RPM, No. of Speeds 1, Voltage 115/208-230V AC, Full Load Amps 15.2/8.2-7.6 A, 145T Frame, Usable @ 208V Usable at 208V, Usable @ 200V Not Usable at 200V, 60 Hz Hz, Motor Service Factor 1.15, Motor Thermal Protection Manual, Ins. Class B, Max. Ambient Temp. 40 Degrees C, Duty Cycle Continuous, Motor Shaft Rotation CCWSE, Motor Enclosure Design Totally Enclosed Fan Cooled
Additional Information
- Country of Origin: MX
- Drop Ship Item: No
- Blind Ship Eligible: No
- LTL Freight Required: No
- Lead Time: Ships in 1 days
- Minimum Order Quantity: 1
- Unit of Measure: EA
- Package Length: 16.10
- Package Width: 10.60
- Package Height: 8.90
- Package Weight: 40.40
Product info last updated on February 4, 2026 12:27pm UTC
Category: Motors
