Vector Motor, 1/2 HP, 1.5 ft.-lb., 230V MPN:056H17T2016
Vector Motor, 1/2 HP, 1.5 ft.-lb., 230V
This 1/2 HP three-phase Vector Motor from Leeson is designed for high-torque applications, delivering 1.5 ft-lb of torque and a nameplate RPM of 1,725. Its wide speed range of 1,000:1 makes it suitable for various applications, including conveyor systems, pumps, and fans. The motor's continuous duty cycle and NEMA Design A rating ensure reliable operation in demanding environments. With a compact 56C frame and a maximum ambient temperature of 104°F, this motor is ideal for use in industrial settings where space and efficiency are crucial. Its 230V AC operation provides a high level of power and control.
Top product features:
- Three Phase Design
- 1,725 Nameplate RPM
- 1,000:1 Speed Range
Top product applications:
- Industrial conveyor systems
- Pumps and compressors
- Material handling equipment
Vector Motor, Three Phase, Motor Design 3-Phase, 1/2 HP, Nameplate RPM 1,725, No. of Speeds 1, Voltage 230V AC, Full Load Amps 1.8 A, 56C Frame, Torque 1.5 ft-lb, Max. Speed 5,400 RPM, Speed Range 1,000:1, Usable @ 208V No, Usable @ 200V No, 60 Hz Hz, Max. Operating Frequency 120 Hz, Motor Service Factor 1, Motor Thermal Protection None, Ins. Class H, Max. Ambient Temp. 104 Degrees F, Duty Cycle Continuous, NEMA Design A, Motor Shaft Rotation CW/CCW
Additional Information
- Country of Origin: ZZ
- Drop Ship Item: No
- Blind Ship Eligible: No
- LTL Freight Required: No
- Lead Time: Ships in 1 days
- Minimum Order Quantity: 1
- Unit of Measure: EA
- Package Length: 11.70
- Package Width: 7.20
- Package Height: 7.20
- Package Weight: 19.40
Product info last updated on February 1, 2026 10:40am UTC
Category: Motors
