Vector Motor, 1.5 lb-ft, 1/2 HP, 230/460 V MPN:056H17T2017
Vector Motor, 1.5 lb-ft, 1/2 HP, 230/460 V
This 1/2 HP, 3-phase Vector Motor from Leeson is designed for high-torque applications that require a wide speed range. With a nameplate RPM of 1,725 and a speed range of 1,000:1, this motor is ideal for use in conveyors, pumps, and other machinery that require a high degree of precision and control. Its compact 56C frame and CW/CCW shaft rotation make it easy to integrate into a variety of systems. The motor's continuous duty cycle and NEMA Design B rating ensure reliable operation in demanding environments, making it a top choice for industrial and commercial applications.
Top product features:
- Three-phase design
- 1.5 ft-lb torque
- Speed range of 1,000:1
Top product applications:
- Conveyor Systems
- Pumps and Water Treatment Equipment
- Fans and Blowers
Vector Motor, Three Phase, Motor Design Three-Phase, 1/2 HP, Nameplate RPM 1,725, No. of Speeds 1, Voltage 230/460V AC, Full Load Amps 1.8/0.90 A, 56C Frame, Torque 1.5 ft-lb, Max. Speed 5,400 RPM, Speed Range 1,000:1, Usable @ 208V Not Usable at 208V, Usable @ 200V Not Usable at 200V, 60 Hz Hz, Max. Operating Frequency 120 Hz, Motor Service Factor 1, Motor Thermal Protection None, Ins. Class H, Max. Ambient Temp. 104 Degrees F, Duty Cycle Continuous, NEMA Design B, Motor Shaft Rotation CW/CCW
Additional Information
- Country of Origin: MX
- Drop Ship Item: No
- Blind Ship Eligible: No
- LTL Freight Required: No
- Lead Time: Ships in 1 days
- Minimum Order Quantity: 1
- Unit of Measure: EA
- Package Length: 12.44
- Package Width: 9.13
- Package Height: 8.06
- Package Weight: 20.00
Product info last updated on February 11, 2026 6:16pm UTC
Category: Motors
