Capacitor-Start/Run General Purpose Motor, 1/2 hp HP, 115/208-230V AC Voltage, 56C Frame MPN:056B11F5303
Capacitor-Start/Run General Purpose Motor, 1/2 hp HP, 115/208-230V AC Voltage, 56C Frame
This 1/2 horsepower capacitor-start/run general purpose motor is designed for a wide range of applications, including industrial and commercial use. With a nameplate RPM of 1,140 and a voltage range of 115/208-230V AC, this motor is suitable for various environments. Its totally enclosed fan-cooled design provides durability and protection from dust and moisture. The motor's continuous duty cycle and high service factor make it ideal for applications with heavy loads. Suitable for use in environments up to 40°C, this motor is a reliable choice for industries such as manufacturing, packaging, and material handling.
Top product features:
- Totally Enclosed Fan Cooled design provides a safe and reliable operating environment.
- Motor Design Capacitor-Start/Run allows for efficient and consistent operation.
- Continuous Duty Cycle capability enables the motor to operate for extended periods without interruption.
Top product applications:
- Pump applications
- Compressor applications
- Fan applications
General Purpose Motor, Single Phase, Motor Design Capacitor-Start/Run, 1/2 hp HP, Nameplate RPM 1,140 RPM, No. of Speeds 1, Voltage 115/208-230V AC, Full Load Amps 9.6/4.8-4.7 A, 56C Frame, Usable @ 208V Usable at 208V, Usable @ 200V Not Usable at 200V, Hz 60/50 Hz, Motor Service Factor 1.15, Max. Ambient Temp. 40 Degrees C, Motor Thermal Protection None, Duty Cycle Continuous, Ins. Class B, Motor Enclosure Design Totally Enclosed Fan Cooled, Motor Shaft Rotation CW/CCW
Additional Information
- Country of Origin: MX
- Drop Ship Item: No
- Blind Ship Eligible: No
- LTL Freight Required: No
- Lead Time: Ships in 1 days
- Minimum Order Quantity: 1
- Unit of Measure: EA
- Package Length: 16.38
- Package Width: 10.50
- Package Height: 8.12
- Package Weight: 35.00
Product info last updated on February 3, 2026 11:40pm UTC
Category: Motors
