Capacitor-Start/Run General Purpose Motor, 1/3 hp HP, 56C Frame, 100-120/200-240V AC Voltage MPN:5KCR46JN0087Y
Capacitor-Start/Run General Purpose Motor, 1/3 hp HP, 56C Frame, 100-120/200-240V AC Voltage
This 1/3 hp Capacitor-Start/Run General Purpose Motor from Leeson is a reliable and efficient solution for a variety of applications. Suitable for use in 100-120/200-240V AC environments, this motor is ideal for powering equipment in manufacturing, commercial, and industrial settings. Its totally enclosed fan-cooled design provides protection from dust and moisture, while its continuous duty cycle and manual thermal protection ensure reliable operation. With a nameplate RPM of 1,725, this motor is perfect for applications requiring moderate speed and torque, such as conveyor systems, pumps, and fans. Its compact 56C frame makes it easy to integrate into existing systems.
Top product features:
- Totally Enclosed Fan Cooled design for improved motor efficiency and reliability
- Single Phase Motor Design with Capacitor-Start/Run capability for efficient operation and reduced energy consumption
- Continuous Duty Cycle for uninterrupted operation and high productivity
Top product applications:
- Pump applications, such as water circulation pumps and sump pumps
- Conveyor systems, including belt conveyors and screw conveyors
- Fans, including centrifugal fans and axial fans
General Purpose Motor, Single Phase, Motor Design Capacitor-Start/Run, 1/3 hp HP, Nameplate RPM 1,725 RPM, No. of Speeds 1, Voltage 100-120/200-240V AC, Full Load Amps 3.8/1.9 A, 56C Frame, Usable @ 208V Not Usable at 208V, Usable @ 200V Usable at 200V, Hz 60/50 Hz, Motor Service Factor 1.35, Max. Ambient Temp. 40 Degrees C, Motor Thermal Protection Manual, Duty Cycle Continuous, Ins. Class B, Motor Enclosure Design Totally Enclosed Fan Cooled, Motor Shaft Rotation CW/CCW
Additional Information
- Country of Origin: MX
- Drop Ship Item: No
- Blind Ship Eligible: No
- LTL Freight Required: No
- Lead Time: Ships in 1 days
- Minimum Order Quantity: 1
- Unit of Measure: EA
- Package Length: 15.14
- Package Width: 10.19
- Package Height: 9.50
- Package Weight: 26.00
Product info last updated on February 10, 2026 1:45pm UTC
Category: Motors
