Vector Motor, 4.5 lb-ft, 1.5 HP, 230/460 V MPN:145THTR5329
Vector Motor, 4.5 lb-ft, 1.5 HP, 230/460 V
This 1.5 HP three-phase vector motor from Leeson is designed for high-performance applications that require precise control and efficiency. With a torque of 4.5 lb-ft and a speed range of 1,000:1, it's ideal for use in industrial automation, robotics, and material handling systems. The motor's NEMA Design A rating ensures reliable operation in a variety of environments, while its Class H insulation provides added protection against overheating. Suitable for continuous duty cycles, this motor is perfect for applications that require high speed and precision, such as conveyor systems, packaging machinery, and textile manufacturing equipment.
Top product features:
- Three Phase Design
- 145TC Frame Construction
- Speed Range of 1,000:1
Top product applications:
- Pumps
- Conveyors
- Fans
Vector Motor, Three Phase, Motor Design 3-Phase, 1 1/2 HP, Nameplate RPM 1,755, No. of Speeds 1, Voltage 230/460V AC, Full Load Amps 4.8/2.4 A, 145TC Frame, Torque 4.5 ft-lb, Max. Speed 5,400 RPM, Speed Range 1,000:1, Usable @ 208V No, Usable @ 200V No, 60 Hz Hz, Max. Operating Frequency 120 Hz, Motor Service Factor 1, Motor Thermal Protection None, Ins. Class H, Max. Ambient Temp. 104 Degrees F, Duty Cycle Continuous, NEMA Design A, Motor Shaft Rotation CW/CCW
Additional Information
- Country of Origin: MX
- Drop Ship Item: No
- Blind Ship Eligible: No
- LTL Freight Required: No
- Lead Time: Ships in 1 days
- Minimum Order Quantity: 1
- Unit of Measure: EA
- Package Length: 15.82
- Package Width: 12.56
- Package Height: 9.38
- Package Weight: 49.00
