GP Mtr, CSCR, TEFC, 3/4 HP, 1140 rpm, 56 MPN:5KCR48WN6066
GP Mtr, CSCR, TEFC, 3/4 HP, 1140 rpm, 56
The Leeson 3/4 HP General Purpose Motor is a reliable and efficient solution for various applications. Suitable for single-phase use, this motor operates at 1,140 RPM and features a 56 frame design. Its capacitor-start/run design provides a high level of performance and efficiency. This motor is ideal for use in residential and commercial settings, such as in HVAC systems, water pumps, and other equipment. Its totally enclosed fan-cooled design ensures durability and long lifespan. With a continuous duty cycle and a maximum ambient temperature of 40 degrees C, this motor is perfect for applications requiring reliable and consistent performance.
Top product features:
- Totally Enclosed Fan Cooled design for improved durability and reduced maintenance
- Single Phase motor design for flexibility and cost-effectiveness
- Continuous duty cycle for high-capacity operation and reliability
Top product applications:
- Industrial machinery
- Pumps
- Fans
General Purpose Motor, Single Phase, Motor Design Capacitor-Start/Run, 3/4 hp HP, Nameplate RPM 1,140 RPM, No. of Speeds 1, Voltage 115/230V AC, Full Load Amps 10.6/5.3 A, 56 Frame, Usable @ 208V Not Usable at 208V, Usable @ 200V Not Usable at 200V, Hz 60 Hz, Motor Service Factor 1, Max. Ambient Temp. 40 Degrees C, Motor Thermal Protection None, Duty Cycle Continuous, Ins. Class B, NEMA Design L, Motor Enclosure Design Totally Enclosed Fan Cooled, Motor Shaft Rotation CW/CCW
Additional Information
- Country of Origin: MX
- Drop Ship Item: No
- Blind Ship Eligible: No
- LTL Freight Required: No
- Lead Time: Ships in 1 days
- Minimum Order Quantity: 1
- Unit of Measure: EA
- Package Length: 15.14
- Package Width: 10.19
- Package Height: 9.50
- Package Weight: 44.00
Product info last updated on January 31, 2026 10:46pm UTC
Category: Motors
