Vector Motor, 4.5 lb-ft, 1 HP, 230/460 V MPN:145THTR5376
Vector Motor, 4.5 lb-ft, 1 HP, 230/460 V
The Leeson Vector Motor is a reliable and efficient solution for a wide range of industrial applications. With a 1 HP output and 4.5 lb-ft of torque, this three-phase motor is perfect for use in manufacturing, material handling, and other high-demand environments. Its continuous duty cycle and NEMA Design A rating ensure smooth and consistent operation, even in the most demanding conditions. Suitable for use in temperatures up to 104°F, this motor is ideal for applications such as conveyor systems, pumps, and fans, where reliability and efficiency are paramount. Its compact design and easy installation make it a great choice for a variety of industries.
Top product features:
- Three-phase design
- Motor thermal protection is not available
- 145TC frame design
Top product applications:
- Pump applications
- Conveyors and material handling equipment
- Fans and blowers
Vector Motor, Three Phase, Motor Design 3-Phase, 1 HP, Nameplate RPM 1,145, No. of Speeds 1, Voltage 230/460V AC, Full Load Amps 3.8/1.9 A, 145TC Frame, Torque 4.5 ft-lb, Max. Speed 5,400 RPM, Speed Range 1,000:1, Usable @ 208V No, Usable @ 200V No, 60 Hz Hz, Max. Operating Frequency 120 Hz, Motor Service Factor 1, Motor Thermal Protection None, Ins. Class F, Max. Ambient Temp. 104 Degrees F, Duty Cycle Continuous, NEMA Design A, Motor Shaft Rotation CW/CCW
Additional Information
- Country of Origin: MX
- Drop Ship Item: No
- Blind Ship Eligible: No
- LTL Freight Required: No
- Lead Time: Ships in 1 days
- Minimum Order Quantity: 1
- Unit of Measure: EA
- Package Length: 19.88
- Package Width: 10.25
- Package Height: 8.12
- Package Weight: 49.00
Product info last updated on January 31, 2026 7:17am UTC
Category: Motors
