Mtr, Cap St, 3/4 HP, 3450, 115/230V, 56J MPN:5KC39QN3219X
Mtr, Cap St, 3/4 HP, 3450, 115/230V, 56J
This Leeson 3/4 HP general-purpose pump motor is designed for continuous duty cycles and is ideal for use in a variety of applications, including water treatment, irrigation, and industrial pumping systems. The motor's capacitor-start design and ball bearings ensure efficient operation and long lifespan. With a maximum ambient temperature of 40 degrees C, it can withstand harsh environments. The motor is also designed with an open dripproof enclosure, making it suitable for use in outdoor applications. Its compact size and standard efficient design make it a reliable and cost-effective solution for a range of industrial and commercial pumping needs.
Top product features:
- Continuous Duty Cycle
- Capacitor-Start Motor Design
- Ball Bearings
Top product applications:
- General Purpose Pump
- Motor Application Pump
- Pump
Jet Pump Motor, Body Dia. 5.6 in, Bolt Circle Dia. 2 15/16 in, CC Number CC003A, Conduit Box Location Exterior, Duty Cycle Continuous, Frame 56J, Hz 60 Hz, Full Load Amps 11.2/5.6-5.3, HP 3/4, Includes Shaft Slinger, Ins. Class B, Lead Length 5 in, 7 in, Length Less Shaft 10 in, Max. Ambient Temp. 40 Degrees C, Motor Application Pump, Motor Bearings Ball, Motor Design Capacitor-Start, Motor Efficiency Group Standard Efficient, Motor Enclosure Design Open Dripproof, Motor Frame Material Steel
Additional Information
- Country of Origin: MX
- Drop Ship Item: No
- Blind Ship Eligible: No
- LTL Freight Required: No
- Lead Time: Ships in 1 days
- Minimum Order Quantity: 1
- Unit of Measure: EA
- Package Length: 15.44
- Package Width: 10.19
- Package Height: 9.50
- Package Weight: 18.00
Product info last updated on April 5, 2026 10:26am UTC
Category: Motors
