Vector Motor, 3.0 lb-ft, 1 HP, 230/460 V MPN:056H17F2021
Vector Motor, 3.0 lb-ft, 1 HP, 230/460 V
The Leeson Vector Motor is a reliable and efficient solution for a variety of applications. With a 1 HP rating and 3.0 lb-ft of torque, this three-phase motor is ideal for use in industrial settings, such as conveyor systems, pumps, and fans. Its high speed range of 1,000:1 and continuous duty cycle make it suitable for demanding operations. The motor's compact design and CW/CCW shaft rotation provide flexibility in installation and use. Its 56C frame and Class H insulation ensure durability and long lifespan, making it a valuable addition to any industrial equipment arsenal.
Top product features:
- Three-phase motor design
- Continuous duty cycle
- Torque of 3.0 lb-ft at 1 HP
Top product applications:
- Pump applications
- Conveyor systems
- Machine tools
Vector Motor, Three Phase, Motor Design 3-Phase, 1 HP, Nameplate RPM 1,725, No. of Speeds 1, Voltage 230/460V AC, Full Load Amps 3.2/1.6 A, 56C Frame, Torque 3 ft-lb, Max. Speed 5,400 RPM, Speed Range 1,000:1, Usable @ 208V No, Usable @ 200V No, 60 Hz Hz, Max. Operating Frequency 120 Hz, Motor Service Factor 1, Motor Thermal Protection None, Ins. Class H, Max. Ambient Temp. 104 Degrees F, Duty Cycle Continuous, NEMA Design A, Motor Shaft Rotation CW/CCW
Additional Information
- Country of Origin: MX
- Drop Ship Item: No
- Blind Ship Eligible: No
- LTL Freight Required: No
- Lead Time: Ships in 1 days
- Minimum Order Quantity: 1
- Unit of Measure: EA
- Package Length: 13.75
- Package Width: 7.88
- Package Height: 8.75
- Package Weight: 27.00
Product info last updated on April 9, 2026 2:22pm UTC
Category: Motors
