Capacitor-Start General Purpose Motor, 1/2 hp HP, 115/230V AC Voltage, 56 Frame MPN:5KC48UN6052
Capacitor-Start General Purpose Motor, 1/2 hp HP, 115/230V AC Voltage, 56 Frame
This 1/2 hp Capacitor-Start General Purpose Motor from Leeson is a reliable and efficient solution for various applications. Suitable for use in 115/230V AC environments, it offers a nameplate RPM of 1,140 and a continuous duty cycle. The motor's open drip-proof design and cradle base mounting type provide easy installation and maintenance. Its 1.25 service factor and 40°C maximum ambient temperature make it suitable for a wide range of applications, including industrial and commercial settings. Ideal for use in machines, pumps, and other equipment, this motor delivers consistent performance and long-lasting reliability.
Top product features:
- Capacitor-start design allows for efficient starting and operation of the motor
- Single-phase operation makes the motor suitable for a wide range of applications
- Open drip-proof enclosure design provides protection against dust and water splashing
Top product applications:
- Pumps
- Fans
- Conveyors
General Purpose Motor, Single Phase, Motor Design Capacitor-Start, 1/2 hp HP, Nameplate RPM 1,140 RPM, No. of Speeds 1, Voltage 115/230V AC, Full Load Amps 9.4/4.7 A, 56 Frame, Usable @ 208V Not Usable at 208V, Usable @ 200V Not Usable at 200V, Hz 60 Hz, Motor Service Factor 1.25, Max. Ambient Temp. 40 Degrees C, Motor Thermal Protection None, Duty Cycle Continuous, Ins. Class B, Motor Enclosure Design Open Drip Proof, Motor Shaft Rotation CW/CCW, Motor Mounting Type Cradle Base
Additional Information
- Country of Origin: MX
- Drop Ship Item: No
- Blind Ship Eligible: No
- LTL Freight Required: No
- Lead Time: Ships in 1 days
- Minimum Order Quantity: 1
- Unit of Measure: EA
- Package Length: 13.69
- Package Width: 7.13
- Package Height: 7.50
- Package Weight: 40.00
Product info last updated on February 24, 2026 6:38am UTC
Category: Motors
