Vector Motor, 3.0 lb-ft, 1 HP, 230/460 V MPN:056H17T5302
Vector Motor, 3.0 lb-ft, 1 HP, 230/460 V
This 1 HP, three-phase vector motor from Leeson offers high performance and efficiency in a compact design. With a torque of 3.0 lb-ft and a nameplate RPM of 1,725, it's perfect for applications requiring precise speed control and high reliability. Suitable for use in industrial environments, this motor excels in applications such as conveyor systems, pumps, and fans. Its continuous duty cycle and NEMA Design A rating ensure consistent performance and long lifespan. With a country of origin in Mexico and a lead time of just one day, this motor is an excellent choice for industries seeking high-quality, reliable power solutions.
Top product features:
- Three phase design
- Continuous duty cycle
- 56C frame
Top product applications:
- Pumps and blowers for industrial processes
- Conveyor systems for material handling
- Fans and blowers for HVAC systems
Vector Motor, Three Phase, Motor Design Three-Phase, 1 HP, Nameplate RPM 1,725, No. of Speeds 1, Voltage 230/460V AC, Full Load Amps 3.0/1.5 A, 56C Frame, Torque 3 ft-lb, Max. Speed 5,400 RPM, Speed Range 1,000:1, Usable @ 208V Not Usable at 208V, Usable @ 200V Not Usable at 200V, 60 Hz Hz, Max. Operating Frequency 120 Hz, Motor Service Factor 1, Motor Thermal Protection None, Ins. Class F, Max. Ambient Temp. 104 Degrees F, Duty Cycle Continuous, NEMA Design A, Motor Shaft Rotation CW/CCW
Additional Information
- Country of Origin: MX
- Drop Ship Item: No
- Blind Ship Eligible: No
- LTL Freight Required: No
- Lead Time: Ships in 1 days
- Minimum Order Quantity: 1
- Unit of Measure: EA
- Package Length: 16.38
- Package Width: 10.50
- Package Height: 8.12
- Package Weight: 39.00
Product info last updated on April 4, 2026 7:10am UTC
Category: Motors
