Vector Motor, 6.0 lb-ft, 1 HP, 230/460 V MPN:145THTN6046
Vector Motor, 6.0 lb-ft, 1 HP, 230/460 V
This 2 HP three-phase vector motor from Leeson is designed for demanding applications requiring high torque and efficiency. With a nameplate RPM of 1,750 and a speed range of 1,000:1, it offers precise control and reliability in processes such as material handling, conveyor systems, and robotics. Its continuous duty cycle and NEMA Design A rating make it suitable for 24/7 operation in industrial environments. The motor's compact design and CW/CCW rotation options provide flexibility in system integration. Its high-performance capabilities make it an ideal choice for manufacturers seeking to optimize production efficiency and reduce downtime.
Top product features:
- Three-phase motor design
- Torque of 6.0 lb-ft
- Speed range of 1,000:1
Top product applications:
- Pump and fan applications
- Conveyor belt systems
- Machine tool applications
Vector Motor, Three Phase, Motor Design Three-Phase, 2 HP, Nameplate RPM 1,750, No. of Speeds 1, Voltage 230/460V AC, Full Load Amps 6.0/3.0 A, 145TC Frame, Torque 6 ft-lb, Max. Speed 5,400 RPM, Speed Range 1,000:1, Usable @ 208V Not Usable at 208V, Usable @ 200V Not Usable at 200V, 60 Hz Hz, Max. Operating Frequency 120 Hz, Motor Service Factor 1, Motor Thermal Protection None, Ins. Class F, Max. Ambient Temp. 104 Degrees F, Duty Cycle Continuous, NEMA Design A, Motor Shaft Rotation CW/CCW
Additional Information
- Country of Origin: ZZ
- Drop Ship Item: No
- Blind Ship Eligible: No
- LTL Freight Required: No
- Lead Time: Ships in 1 days
- Minimum Order Quantity: 1
- Unit of Measure: EA
- Package Length: 15.80
- Package Width: 13.00
- Package Height: 10.90
- Package Weight: 72.00
Product info last updated on February 16, 2026 10:45am UTC
Category: Motors
