Capacitor-Start Fan and Blower Motor, 3/4 HP, 277V AC Voltage, 56 Frame, 1, 725 Nameplate RPM MPN:056B17D2013
Capacitor-Start Fan and Blower Motor, 3/4 HP, 277V AC Voltage, 56 Frame, 1, 725 Nameplate RPM
This 3/4 HP capacitor-start fan and blower motor from Leeson is designed for single-phase applications, delivering 1,725 RPM at 277V AC voltage. Ideal for use in commercial and industrial settings, it features a 56 frame size and a continuous duty cycle. The motor's open drip-proof enclosure and cradle base mounting make it easy to install and maintain. With a service factor of 1.25 and a maximum ambient temperature of 70°C, this motor is suitable for a variety of applications, including ventilation systems, exhaust fans, and blowers. Its compact size and high efficiency make it a reliable choice for demanding environments.
Top product features:
- Capacitor-start design for efficient starting and operation
- Single-phase motor for use in a variety of applications
- Continuous duty cycle for reliable operation under heavy loads
Top product applications:
- Industrial ventilation systems
- Air handling units
- Dust collection systems
Fan and Blower Motor, Single Phase, Motor Design Capacitor-Start, 3/4 hp HP, Nameplate RPM 1,725 RPM, No. of Speeds 1, Voltage 277V AC, 4.3 A Full Load Amps, 56 Frame, 60 Hz Hz, Usable @ 208V Not Usable at 208V, Motor Service Factor 1.25, Motor Thermal Protection None, Ins. Class B, Duty Cycle Continuous, Max. Ambient Temp. 70 Degrees C, Motor Shaft Rotation CW/CCW, Motor Enclosure Design Open Drip Proof, Motor Mounting Type Cradle Base, Motor Frame Material Steel
Additional Information
- Country of Origin: MX
- Drop Ship Item: No
- Blind Ship Eligible: No
- LTL Freight Required: No
- Lead Time: Ships in 1 days
- Minimum Order Quantity: 1
- Unit of Measure: EA
- Package Length: 15.82
- Package Width: 12.56
- Package Height: 9.38
- Package Weight: 27.00
Product info last updated on May 5, 2026 4:45pm UTC
Category: Motors
