3, 1725, Dp, 56Hz, 3/60/208-230/460 MPN:056T17D5350
3, 1725, Dp, 56Hz, 3/60/208-230/460
The Leeson Three-Phase Fan and Blower Motor is a reliable and efficient solution for a wide range of applications, including industrial ventilation, HVAC systems, and material handling. With a robust 3 horsepower design and 1,725 RPM nameplate speed, this motor can handle demanding tasks with ease. Its compact 56HZ frame and open drip-proof enclosure ensure a long lifespan and easy maintenance. Suitable for use at 208-230/460V AC, this motor is ideal for applications that require continuous operation in temperatures up to 40°C. Its high service factor and automatic thermal protection make it a valuable addition to any industrial setup.
Top product features:
- Three-Phase Operation
- Usable at 208V and 60 Hz
- Open Drip Proof Enclosure Design
Top product applications:
- HVAC systems
- Compressors
- Manufacturing machinery
Fan and Blower Motor, Three Phase, Motor Design Three-Phase, 3 hp HP, Nameplate RPM 1,725 RPM, No. of Speeds 1, Voltage 208-230/460V AC, 9.2-8.6/4.3 A Full Load Amps, 56HZ Frame, 60 Hz Hz, Usable @ 208V Usable at 208V, Motor Service Factor 1.15, Motor Thermal Protection Auto, Ins. Class B, Duty Cycle Continuous, Max. Ambient Temp. 40 Degrees C, Motor Shaft Rotation CW/CCW, Motor Enclosure Design Open Drip Proof, Motor Mounting Type Cradle Base, Motor Frame Material Steel
Additional Information
- Country of Origin: MX
- Drop Ship Item: No
- Blind Ship Eligible: No
- LTL Freight Required: No
- Lead Time: Ships in 1 days
- Minimum Order Quantity: 1
- Unit of Measure: EA
- Package Length: 16.56
- Package Width: 7.50
- Package Height: 7.50
- Package Weight: 48.00
