Vector Motor, 4.5 lb-ft, 1.5 HP, 230/460 V MPN:145THTR15540
Vector Motor, 4.5 lb-ft, 1.5 HP, 230/460 V
This 1.5 HP three-phase vector motor from Leeson is designed for demanding applications, delivering 4.5 lb-ft of torque and a nameplate RPM of 1,755. Ideal for use in industrial settings, it features a high speed range of 1,000:1 and a maximum operating frequency of 120 Hz. With a compact 145TC frame, it's perfect for space-constrained areas. The motor's continuous duty cycle and NEMA Design A rating ensure reliable operation in a variety of applications, including conveyor systems, pumps, and fans. Its high performance and efficiency make it a valuable addition to any industrial operation.
Top product features:
- Three-phase operation
- 145TC frame design
- Continuous duty cycle operation
Top product applications:
- High-speed machining centers
- Automotive manufacturing equipment
- Textile machinery
Vector Motor, Three Phase, Motor Design Three-Phase, 1 1/2 HP, Nameplate RPM 1,755, No. of Speeds 1, Voltage 230/460V AC, Full Load Amps 4.8/2.4 A, 145TC Frame, Torque 4.5 ft-lb, Max. Speed 5,400 RPM, Speed Range 1,000:1, Usable @ 208V Not Usable at 208V, Usable @ 200V Not Usable at 200V, 60 Hz Hz, Max. Operating Frequency 120 Hz, Motor Service Factor 1, Motor Thermal Protection None, Ins. Class H, Max. Ambient Temp. 104 Degrees F, Duty Cycle Continuous, NEMA Design A
Additional Information
- Country of Origin: US
- Drop Ship Item: Yes
- Blind Ship Eligible: No
- LTL Freight Required: No
- Lead Time: Ships in 15 days
- Minimum Order Quantity: 1
- Unit of Measure: EA
- Package Length: 19.88
- Package Width: 10.25
- Package Height: 8.12
- Package Weight: 51.00
Product info last updated on February 28, 2026 10:48am UTC
Category: Motors
