Capacitor-Start General Purpose Motor, 1/4 hp HP, 115/208-230V AC Voltage, 56C Frame MPN:056C11F5302
Capacitor-Start General Purpose Motor, 1/4 hp HP, 115/208-230V AC Voltage, 56C Frame
This Leeson Capacitor-Start General Purpose Motor is a reliable and efficient solution for various applications. With a 1/4 hp rating and 1,140 RPM, it's perfect for tasks that require moderate power and speed. Suitable for use in 115/208-230V AC environments, it can be used at 208V and is ideal for continuous operation in temperatures up to 40°C. Its totally enclosed fan-cooled design ensures long motor life and reduced maintenance. The motor is suitable for applications such as pumps, fans, and conveyor systems, making it a versatile addition to any industrial setup.
Top product features:
- Totally Enclosed Fan Cooled design provides a safe and efficient operation in harsh environments.
- Usable at 208V offers flexibility in installation and compatibility with various electrical systems.
- 1,140 RPM nameplate speed allows for precise control and optimized performance in applications requiring a specific speed.
Top product applications:
- Pumps
- Fans
- Air Compressors
General Purpose Motor, Single Phase, Motor Design Capacitor-Start, 1/4 hp HP, Nameplate RPM 1,140 RPM, No. of Speeds 1, Voltage 115/208-230V AC, Full Load Amps 6.8/3.4-3.1 A, 56C Frame, Usable @ 208V Usable at 208V, Usable @ 200V Not Usable at 200V, Hz 60 Hz, Motor Service Factor 1.15, Max. Ambient Temp. 40 Degrees C, Motor Thermal Protection None, Duty Cycle Continuous, Ins. Class B, Motor Enclosure Design Totally Enclosed Fan Cooled, Motor Shaft Rotation CW/CCW
Additional Information
- Country of Origin: MX
- Drop Ship Item: No
- Blind Ship Eligible: No
- LTL Freight Required: No
- Lead Time: Ships in 1 days
- Minimum Order Quantity: 1
- Unit of Measure: EA
- Package Length: 16.12
- Package Width: 10.25
- Package Height: 9.12
- Package Weight: 24.00
