Capacitor-Start/Run General Purpose Motor, 1 1/2 hp HP, 115/208-230V AC Voltage, 56H Frame MPN:056B17DRR70022A1
Capacitor-Start/Run General Purpose Motor, 1 1/2 hp HP, 115/208-230V AC Voltage, 56H Frame
This 1.5 HP single-phase motor from Leeson is a reliable and efficient choice for a variety of applications. Featuring a capacitor-start/run design, it provides smooth and quiet operation. Suitable for use in 115/208-230V AC environments, it's perfect for industrial and commercial settings. With a maximum ambient temperature of 40°C and a service factor of 1.15, it's designed to handle demanding tasks. Its open drip-proof enclosure and rigid base mounting make it easy to integrate into existing systems. Ideal for use in fans, pumps, and conveyor systems, this motor offers reliable performance and long-lasting durability.
Top product features:
- Capacitor-start/run design provides efficient starting and running performance
- Single-phase motor operation allows for use in a variety of applications
- Open drip-proof enclosure design protects against dust and water splashes
Top product applications:
- Industrial laundry equipment
- Commercial refrigeration units
- Manufacturing machinery
General Purpose Motor, Single Phase, Motor Design Capacitor-Start/Run, 1 1/2 hp HP, Nameplate RPM 1,725 RPM, No. of Speeds 1, Voltage 115/208-230V AC, Full Load Amps 12.6/6.4-6.3 A, 56H Frame, Usable @ 208V Usable at 208V, Usable @ 200V Not Usable at 200V, Hz 60 Hz, Motor Service Factor 1.15, Max. Ambient Temp. 40 Degrees C, Motor Thermal Protection Auto, Duty Cycle Continuous, Ins. Class B, Motor Enclosure Design Open Drip Proof, Motor Shaft Rotation CW/CCW, Motor Mounting Type Rigid Base
Additional Information
- Country of Origin: MX
- Drop Ship Item: No
- Blind Ship Eligible: No
- LTL Freight Required: No
- Lead Time: Ships in 1 days
- Minimum Order Quantity: 1
- Unit of Measure: EA
- Package Length: 16.38
- Package Width: 10.50
- Package Height: 9.62
- Package Weight: 47.45
Product info last updated on January 24, 2026 12:09am UTC
Category: Motors
