Capacitor-Start/Run General Purpose Motor, 3/4 hp HP, 115/208-230V AC Voltage, 56 Frame MPN:056B17DRR70004A1
Capacitor-Start/Run General Purpose Motor, 3/4 hp HP, 115/208-230V AC Voltage, 56 Frame
This 3/4 hp capacitor-start/run general purpose motor from Leeson is a reliable and efficient choice for a variety of applications. Suitable for use in 115/208-230V AC environments, it offers a high service factor of 1.25 and a maximum ambient temperature of 40 degrees C. The motor features an open drip proof design and is rated for continuous duty cycles. Its compact size and rigid base mounting make it ideal for use in industrial settings, such as manufacturing facilities, warehouses, and construction sites, where reliable power is essential. Its 1,725 RPM nameplate speed ensures consistent performance.
Top product features:
- Single Phase Motor Design
- Capacitor-Start/Run Motor Design
- Continuous Duty Cycle
Top product applications:
- Industrial laundry equipment
- Pumps for residential water supply
- Fans for commercial ventilation systems
General Purpose Motor, Single Phase, Motor Design Capacitor-Start/Run, 3/4 hp HP, Nameplate RPM 1,725 RPM, No. of Speeds 1, Voltage 115/208-230V AC, Full Load Amps 6.6/3.5-3.3 A, 56 Frame, Usable @ 208V Usable at 208V, Usable @ 200V Not Usable at 200V, Hz 60 Hz, Motor Service Factor 1.25, Max. Ambient Temp. 40 Degrees C, Motor Thermal Protection Auto, Duty Cycle Continuous, Ins. Class B, Motor Enclosure Design Open Drip Proof, Motor Shaft Rotation CW/CCW, Motor Mounting Type Rigid Base
Additional Information
- Country of Origin: MX
- Drop Ship Item: No
- Blind Ship Eligible: No
- LTL Freight Required: No
- Lead Time: Ships in 1 days
- Minimum Order Quantity: 1
- Unit of Measure: EA
- Package Length: 16.38
- Package Width: 10.50
- Package Height: 9.62
- Package Weight: 38.54
Product info last updated on February 7, 2026 9:15am UTC
Category: Motors
