Capacitor-Start/Run General Purpose Motor, 1/2 hp HP, 120/240V AC Voltage, 56C Frame MPN:056B17D11029
Capacitor-Start/Run General Purpose Motor, 1/2 hp HP, 120/240V AC Voltage, 56C Frame
This 1/2 horsepower capacitor-start/run general purpose motor from Leeson is designed for a wide range of applications, including industrial and commercial use. Its single-phase design and 1,725 RPM nameplate speed make it suitable for applications where a moderate level of power is required. The motor's open drip-proof enclosure and continuous duty cycle enable it to operate in a variety of environments, from dry to damp locations. With a service factor of 1.25 and automatic thermal protection, this motor provides reliable and efficient performance in applications such as pumps, fans, and conveyor systems.
Top product features:
- Capacitor-start/run design for improved efficiency and reliability
- Single phase motor for use in a variety of applications
- Open drip-proof design for protection against dust and water ingress
Top product applications:
- Pumps
- Fans
- Compressors
General Purpose Motor, Single Phase, Motor Design Capacitor-Start/Run, 1/2 hp HP, Nameplate RPM 1,725 RPM, No. of Speeds 1, Voltage 120/240V AC, Full Load Amps 4.4/2.2 A, 56C Frame, Usable @ 208V Not Usable at 208V, Usable @ 200V Usable at 200V, Hz 60/50 Hz, Motor Service Factor 1.25, Max. Ambient Temp. 40 Degrees C, Motor Thermal Protection Auto, Duty Cycle Continuous, Ins. Class B, Motor Enclosure Design Open Drip Proof, Motor Shaft Rotation CW/CCW, Motor Mounting Type C-Face, Rigid Base
Additional Information
- Country of Origin: MX
- Drop Ship Item: No
- Blind Ship Eligible: No
- LTL Freight Required: No
- Lead Time: Ships in 1 days
- Minimum Order Quantity: 1
- Unit of Measure: EA
- Package Length: 16.38
- Package Width: 10.50
- Package Height: 9.62
- Package Weight: 25.00
Product info last updated on February 23, 2026 1:07am UTC
Category: Motors
